Functions (Items) Initialization
(setting)
APERTURE 00
ADJ. BAR POSI LOWER
COLOR TEMP 6500
COLOR SYSTEM AUTO
COMPO. LEVEL 00
RUSH DELAY STD.
PICTURE SUB ADJ.
CONTRAST 00
BRIGHT 00
CHROMA 00
PHASE 00
H. POSITION 00
V. POSITION 00
WHITE BALANCE
R. CUT OFF
00
G. CUT OFF 00
B. CUT OFF 00
R. DRIVE 00
B. DRIVE 00
CONTROL LOCK OFF
STATUS DISPLAY ON
REMOTE SYSTEM MAKE
INPUT REMOTE
A – D
CHROMA 00
PHASE 00
CONTRAST 00
BRIGHT 00
VOLUME 20
RESET
Are you sure ?
“Yes” then <+>
“No” then
Sorts
-UP
MENU> screen
V o lume
HOW TO INITIALIZE THE
SETTING
SCREEN DISPLAY AND SELECTIONS IN THE
RESET MODE
You can set
1. Press the Power ( ) switch to turn the power
OFF (activate the standby mode).
The RESET screen is displayed.
Initial settings
RESET screen
2. While pressing both MENU button and CHROMA/
PHASE button, press the Power ( ) switch to turn
the power ON.
3. Setting
ⅷ Initialization is required.
ⅷ Initialization is not required.
Press the VOLUME/SELECT [+] button.
* Initialization is completed, and the
RESET screen disappears.
Press the MENU button.
* Initialization is aborted, and the
RESET screen disappears.
● The RESET screen will not be
displayed if the MENU or CHROMA/PHASE buttons are
pressed for a very short time. Keep pressing them until
the display screen appears.
Note:
POWER
MENU CHROMA
PHASE
POWER
MENU
VOLUME/SELECT
Picture adjustment
15 14
Set-up menu items Purpose Settings
PICTURE SUB ADJ. Image sub adjustment Selects CONTRAST/BRIGHT/CHROMA/PHASE. The
selected setting screen is shown. Select the function display for
adjustment.
CONTRAST Adjusts contrast.
BRIGHT Adjusts brightness.
CHROMA Adjusts color density. *1
PHASE Adjusts hue. *1
H. POSITION Adjusts the horizontal position of the
screen (+: Horizontal position shifts
to the right/-: Horizontal position shifts to
the left)
V. POSITION Adjusts the vertical position of the screen
(+: Vertical position moves up/-: Vertical
position moves down)
WHITE BALANCE Adjusts the white balance. Selects the drive (DRV) or cut off (CUTO) adjustment. The selected
setting screen is shown. Select the function display for adjustment.
DRIVE R. DRIVE Adjusts red level.
B. DRIVE Adjusts blue level.
CUT OFF R. CUT OFF Adjusts red cut off.
G. CUT OFF Adjusts green cut off.
B. CUT OFF Adjusts blue cut off.
CONTROL LOCK Sets the operation buttons on the front
panel to control lock mode.
STATUS DISPLAY Sets the status display of the color system.
REMOTE SYSTEM Sets the external control function method. *2
INPUT REMOTE Sets external control of input selection.
(Shown only when REMOTE SYSTEM is
*2
set to MAKE.)
4. To set the other set-up menu items, repeat the
procedures 2 and 3.
5. Press the MENU button to quit.
Notes:
● When the CONTROL LOCK function is
set to ON, pressing operation buttons
on the front panel will display the
message “CONTROL LOCK ON!” on
the screen for about 3 seconds.
● The CONTROL LOCK function is
maintained even when the power is
turned off.
● To turn off the CONTROL LOCK
function, while holding the MENU button
press the CHROMA/PHASE button.
Then set the CONTROL LOCK function
to OFF.
● Even when the CONTROL LOCK
function is set to ON, the following
operations are available:
– Power Switch operation
– Volume control with the VOLUME/
SELECT buttons
– Display or disappear of the
MENU> screen.
● The STATUS DISPLAY function can be
set to display (ON) or not display (OFF)
the present color system when the
power is turned on or the input signal is
changed. Refer to page 9 for more
information.
● When REMOTE SYSTEM is set to
MAKE and any one of the INPUT A to D
buttons, the UNDER SCAN button,
COLOR OFF button or the ASPECT
button is pressed, “REMOTE ON!”
appears on screen for about 3 seconds.
(Not shown with CONTROL LOCK set
to ON.)
● When REMOTE SYSTEM is set to
TRG, the front panel controls can be
operated.
● INPUT REMOTE and REMOTE
SYSTEM are enabled when REMOTE
ENABLE is set to ON.
Front panel Function
Contents
button displayed
MENU EXIT
Quit (or Release) the
MENU
– 5 • • • – 01 00 +1 • • • +5
– 5 • • • – 01 00 +1 • • • +5
O F F O N
O F F O N
M A K E T R G .
A – D A / B
– 10 – 9 – 01 00 +01 +09 +10 • • • •
– 20 – 1 9 – 01 00 +01 +19 +20 • • • •
*1 May not be shown depending on the type of signals input.
*2 Refer to HOW TO USE EXTERNAL CONTROL on page 18 for more details.
Note:
Setting Description
MAKE Make contact system: Controls the function using the control
terminal’s short-circuit and open (short-circuits or opens 15th
terminal (GND)).
TRG. Trigger system: Controls the function by short-circuiting (short-
circuits or opens 15th terminal (GND)) with pulse (about 1 sec.)
A-D Switches the input by short-circuiting a specified signal line in
INPUT A, B, C, or D.
A/B Switches between INPUT A and INPUT B with D-sub pin 2.
– 10 – 9 – 01 00 +01 +09 +10 • • • •
– 10 – 9 – 01 00 +01 +09 +10 • • • •
– 10 – 9 – 01 00 +01 +09 +10 • • • •
