Connecting (Continued)
2 Preparation
z
Set ACOMPB in the setting menu to AY Pb/Cb Pr/CrB. (pP27 - P )
Connecting via HDMI Cable Or HDMI-DVI Conversion Cable
Connecting via Component Video Cable
HDMI output terminal
HDMI cable (sold separately)
DVD recorder
To HDMI 1 or HDMI 2 input terminal
This unit
DVI output terminal
HDMI-DVI conversion cable (sold separately)
Component video output terminals
Component video cable
(sold separately)
DVD player
To component video input terminals
This unit
C
R
/P
R
(Red)
C
B
/P
B
(Blue)
Y (Green)
