6
Specifications
Main Dust Collection Kits
Model Numbers Stock Numbers
DC-1200BK-1 (Single Phase, with 30 Micron Bag Filter Kit) .................. .................................. 710700BK
DC-1200BK-3 (Three Phase, with 30 Micron Bag Filter Kit) .................. .................................. 710720BK
DC-1200CK-1 (Single Phase, with Canister Filter Kit) ........................... .................................. 710700CK
DC-1200CK-3 (Three Phase, with Canister Filter Kit) ........................... .................................. 710720CK
Base Machine
Stock Number.............................................................................. 710700 ................................... 710720
Impeller Diameter ................................................................................ 12 .......................................... 12
Sound Rating at 3 foot distance .................................................. 70-80 db ................................. 70-80 db
1-Hose Connection Diameter (in.) ...........................................................6 ............................................ 6
2-Hose Connection Diameter (in.) ...........................................................4 ............................................ 4
Air Flow (CFM) ............................................................................... 1,200 ......................................1.200
Velocity at 4” (FPM) ...................................................................... 13,745 .................................... 13,745
Static Pressure (inch of water) ........................................................... 11.5 ....................................... 11.5
Overall Dimensions, approx.(Bag filter kit installed)(in.) .... 37L x 28W x 79H .................... 37L x 28W x 79H
Motor, TEFC ............................................................ 2HP, 1PH, 230V only ............... 2HP, 3PH, 230/460V
................................................................................................. 8A, 60Hz ...... Prewired 230V, 6/3A, 60Hz
Net Weight, approximate (lbs)............................................................. 127 ........................................ 127
30 Micron Filter Bag Kit
Stock Number......................................................................................................................... 708636F
Filter Bag Efficiency ...................................................................................... 96% of 30 micron particles
Filter Bag Length, installed (in.).......................................................................................................... 32
Filter and Collector Bag Diameter (in.) ................................................................................................ 20
Collector Bag Capacity (cu. ft.).......................................................................................................... 5.3
Collector Bag Length, installed (in.) .................................................................................................... 29
Canister Filter Kit
Stock Number......................................................................................................................... 708639B
Canister Length (in.).......................................................................................................................... 25
Canister Efficiency ................................................... 86% of 1 micron particles; 98% of 2 micron particles
Collector Bag Diameter (in.)............................................................................................................... 20
Collector Bag Capacity (cu. ft.).......................................................................................................... 5.3
Collector Bag Length, installed (in.) .................................................................................................... 29
5 Micron Filter Bag Kit (Optional Accessory)
Stock Number...................................................................................................................... 708636MF
Filter Bag Efficiency .................................... 98% of 5 micron particles; 92% of 3 micron; 74% of 1 micron
Filter Bag Length, installed (in.).......................................................................................................... 32
Filter and Collector Bag Diameter (in.) ................................................................................................ 20
Collector Bag Capacity (cu. ft.).......................................................................................................... 5.3
Collector Bag Length, installed (in.) .................................................................................................... 29
IR Remote Control Unit (Optional Accessory)
Stock Number (main unit and remote control switch) (115V only) ............................................... 708636D
Stock Number (Remote Control Switch only) ............................................................................ 708636T
The above specifications were current at the time this manual was published, but because of our policy of
continuous improvement, Walter Meier (Manufacturing) Inc., reserves the right to change specifications at any
time and without prior notice, without incurring obligations.
Read and understand the entire contents of this manual before attempting set-up or
operation! Failure to comply may cause serious injury.
