– 57 –
Specifications
Amplifier
Output Power (IEC 268-3/DIN):
19 W per channel, min. RMS, both channels driven
into 6
Ω
at 1 kHz, with no more than 0.9% total
harmonic distortion
Audio input sensitivity/Impedance (at 1 kHz)
Analog input:
LINE IN: 125 mV/47 k
Ω
(at “LEVEL 2”)
500 mV/47 k
Ω
(at “LEVEL 1”)
1.3 V/47 k
Ω
(at “LEVEL 3”)
Digital input:
LINE DIGITAL IN: OPTICAL
Signal wave length: 660 nm
Input level: –23 dBm to –15 dBm
(With the built-in sampling rate
converter, corresponding to 32 kHz/
44.1 kHz/48 kHz)
Audio output level/Impedance (at 1 kHz)
Analog output:
LINE OUT: 160 mV/2.2 k
Ω
Digital output:
3CD DIGITAL OUT: OPTICAL
Signal wave length: 660 nm
Output level: –23 dBm to –15 dBm
Speakers/Impedance: 6
Ω
— 16
Ω
Tuner
FM tuning range:
87.50 MHz — 108.00 MHz
AM (MW/LW) tuning range:
MW: 522 kHz — 1 629 kHz
LW: 144 kHz — 288 kHz
