EN
57
1 CONNECT DOCKING STATION TO
TV OR VCR
Connect as shown in the illustration (
੬
pg. 56).
If Using A VCR . . . go to step 2.
If not . . . go to step 3.
2 CONNECT VCR OUTPUT TO TV
INPUT
Refer to your VCR’s instruction manual.
3 TURN ON POWER
4 SELECT TV’S VIDEO MODE
Set the TV to the channel or mode appropriate
for video playback.
NOTES:
● When using the provided VIDEO/AUDIO cable
(Docking Station to TV or VCR), DC cord, S-
VIDEO cable or editing cable, make sure you
connect the end of the cable with the core filter to
the Docking Station. The core filter improves
performance of equipment.
● If TV/VCR is equipped with only one audio
connector, use a conversion plug (commercially
available).
Using the remote control unit with the camcorder attached to the Docking Station
While the camcorder is attached to the Docking Station, the camcorder’s remote sensor does not function.
Point the remote control at the sensor located on the Docking Station.
