ENGINE:
155 Engine HP (114 kW) [97/68/EC] @ 2100 RPM
127 PTO Horsepower (95 kW) at 2100 RPM
6 Cylinders, John Deere PowerTech Plus Engine
6.8 Liter (414 Cu. In.) Displacement,
Tier 3 Emissions Level
2100 Rated Engine Speed
High Pressure Common Rail
Variable Geometry Turbocharger and
Exhaust Gas Recirculation
Dual Temp Cooling System
PowerCore Air Filtration System with Permanent
Pre-Cleaning and Safety Element
Underhood Muffler with Deluxe Corner
Post Exhaust
66 Gal (250 L) Fuel Tank Capacity
Intelligent Power Management
TRANSMISSION:
16/16 PowrQuad PLUS; 19 mph (30km/h)
Electronic LH Reverser
Wet Multi-Disk Clutch
Park Lock
Neutral Safety Start System
STEERING, BRAKES, DIFFERENTIAL:
Hydrostatic Steering
Wet-Disk Hydraulic Power Brakes
Rear Axle Differential Lock
HYDRAULICS:
Pressure and Flow Compensated (PFC)
29 GPM (110 L/min) Pump Flow at 2100 RPM
Two 300 Series SCV's; Mechanical with ISO Breakaway
Couplers
REAR PTO:
540/1000 RPM, 1-3/8 In. Independent Rear PTO,
Reversible Shaft and PTO Master Shield
Electrohydraulic Activation
Wet Multi-Disk Clutch
Neutral Start Safety System
Seat Activated PTO Warning
ROCKSHAFT, HITCH AND DRAWBAR:
Electronic Hitch
Category 2, 3-Point Hitch
Electrohydraulic Hitch Control
Two Rear Fender Hitch Controls
8800 Lb. Lift Capacity
Electronic Lower Link Draft Sensing
Telescopic Draft Links
Category 2 Swinging Drawbar
INSTRUMENTATION:
Tachometer
Speedometer
Hour Meter
Fuel Gauge
Engine Oil Pressure Indicator Light
Coolant Temperature
PTO Engagement
Engine Air Filter Restriction Indicator
Alternator
Directional Indicators
Hazard Switch
CAB OPERATOR STATION:
ComfortGard Cab with Air Conditioning
and Heater
Two Panorama Doors
Front Windshield Wiper
Air Suspended ComfortCommand Seat
with Seat Belt
Tilt/Telescopic Steering Column
Operational Controls Console Mounted
Floor Mat
Foot Throttle Control
Power Outlet
Pre-Radio Wiring and Speaker Package
Overhead Courtesy Light
Rear View Mirror
Cup Holder
ELECTRICAL:
Key Shutoff
12 Volt Electrical System
12 Volt Battery, 1230 Cold Cranking Amps
120 Amp Alternator
7 Terminal ASAE Outlet Socket
LIGHTS:
Four Front Grille Headlights
Two Belt Line Mounted Lights
Four Front Roof Lights
Two Rear Roof Lights
Four Roof Mounted Flashing
Hazard Lights
Two Rear Fender Tail Lights with
Brake Lights
FRONT AXLE WHEELS AND TIRES:
MFWD
Steel Wheels
Electrohydraulic MFWD Engagement
380/85R28 In.
133A8 R1 Radial Tires
REAR AXLE WHEELS AND TIRES:
Rack and Pinion Axle;
96 In. Width x 3.385 In. (86 mm) Diameter
Two Cast Inner Wheels
Two 18.4R38 In.
149A8 R1 Radial Tires
MISCELLANEOUS:
Operator's Manual (English) and Holder
SMV Emblem
Available for the United States, Canada, Mexico, Central America, Australia, South Korea, Israel and Egypt Only.
CODE
ATTACHMENT
IDENTIFIER
DESCRIPTION
SUGGESTED
LIST PRICE
USD ($)
Select One Code From Each Required Category
AGRICULTURAL PRODUCTS
JOHN DEERE TRACTORS
7330 ComfortGard Premium Cab Tractor
Equipment for Base Machine
16 May 2012 US & Canada
2-Tractors-05600- 1
