ENGINE:
98 Engine HP (72.7 kw) [97/68/EC] @ 2100 RPM
82 PTO Horsepower (61.4 kW) @ 2100 rpm
4-Cylinders, John Deere PowerTech (2-Valve) Diesel
4.5 Liter (276 Cu. In) Displacement, Tier 3
2100 Rated Engine Speed
Mechanical, Rotary Injection Pump
Fixed Turbocharger, Intercooled
Dual Temperature Cooling System with
Viscous Drive Fan
PowerCore Air Filtration System
Underhood Muffler with Vertical Exhaust
41.7 Gal (158 L) Fuel Tank Capacity
TRANSMISSION:
9 Forward / 9 Reverse Top Shaft Synchronized
PowrReverser 17.6 mph (28.3 km/h)
Mechanical Hydraulic Left Hand Reverser
Wet Multi-Disk Clutch
Mechanically Actuated Park Brake
Neutral Safety Start System
STEERING, BRAKES, DIFFERENTIAL:
Hydrostatic Steering
Sealed Wet Disk Brake
Mechanically Actuated Rear Differential Lock
HYDRAULICS:
Open Center, Constant-Flow Hydraulic System
17.6 GPM (66.6 L/min) Pump Flow @ 2100 RPM
Two Mechanical Rear Selective Control Valves
with ISO Breakaway Couplers
REAR PTO:
540/1000 PTO Speeds, 1-3/8 In. Independent
Rear PTO
Reversible Shaft and PTO Master Shield
Mechanical Activation
Dry PTO Clutch
PTO Neutral Start Safety System
Seat Activated PTO Warning
ROCKSHAFT, HITCH AND DRAWBAR:
Rockshaft Internally Mounted
Category 2, 3-Point Hitch with Center Link
Mechanical Hitch Control
6,800 Lb. Lift Capacity
Mechanical Lower Link Draft Sensing
Telescopic Draft Links
Sway Chain Retainers
Category 2 Drawbar; Swinging
Drawbar Clevis
Safety Chain Holder
INSTRUMENTATION:
Engine RPM
Groundspeed
Hour of Operation
Fuel Level
Engine Oil Pressure
Engine Coolant Temperature
Rear PTO Engagement
Engine Air Filter
Alternator
Directional Indicators
Hazard Switch
OPEN OPERATOR STATION:
Two Post Foldable ROPS with Seat Belt,
Less Canopy
Flat Platform with Steel Fenders
Left Hand Foot Steps
Operational Controls Location -
Right Hand Console
Mechanical Suspension Seat with Armrest
and Seat Belt
Tilt / Telescopic Steering Column
Foot Throttle Control
ELECTRICAL:
Key Shutoff
12-Volt Electrical System
One 12-Volt Battery, 925 Cold Cranking Amps
90-Amp Alternator
7 Terminal (ASAE) Outlet Socket
LIGHTS:
Two Front Headlights
One Rear ROPS Mounted Work Light
Two ROPS Hazard Lights
Two Rear Fender Tail Lights with Brake Lights
FRONT AXLE WHEELS AND TIRES:
MFWD Front Axle with Limited Slip Differential
Two Multi-Position Steel Wheels
Mechanical MFWD Engagement, Left Side
13.6-24 In.
6PR R1 Bias Tires
REAR AXLE WHEELS AND TIRES:
Flange Axle
Eight Position Steel Wheels
18.4-34 In.
8PR R1 Bias
MISCELLANEOUS:
Operator's Manual (English) and Holder
SMV Emblem
Horn
CODE
ATTACHMENT
IDENTIFIER
DESCRIPTION
SUGGESTED
LIST PRICE
USD ($)
Select One Code From Each Required Category
BASE MACHINE
EX-WORKS Laredo, Texas
655BP 6100D Open Operator Station Tractor (82 PTO hp) 47,735.00
AGRICULTURAL PRODUCTS
JOHN DEERE TRACTORS
6100D Open Operator Station Tractor (82 PTO hp)
Equipment for Base Machine
16 May 2012 US & Canada
2-Tractors-02800- 1
