ENGINE:
155 Engine HP (114 kW) [97/68 EC] @ 2100 RPM
127 PTO Horsepower (95 kW) @ 2100 RPM
6 Cylinders, John Deere PowerTech E
6.8 Liter (414 Cu. In.) Displacement, Tier 3
Emissions Level
2100 Rated Engine Speed
High Pressure Common Rail
Turbocharged
Dual Temperature Cooling System
Dry Type Air Cleaner with Safety Element
and PreCleaner
Underhood Muffler with Vertical Exhaust
83 Gal (315 L) Fuel Tank Capacity
TRANSMISSION:
16 Forward/16 Reverse PowrQuad PLUS
Transmission 19 mph (30km/h)
Wet Multi-Disk Clutch
Park Lock
Neutral Safety Start System
STEERING, BRAKES, DIFFERENTIAL:
Hydrostatic Steering
Wet-Disk Hydraulic Power Brakes
Rear Axle Differential Lock
HYDRAULICS:
Load Sensing Constant Flow Pressure
Compensated (PC) System
21.1 GPM (81 L/min) Pump Flow at 2100 RPM
1 SCV; Mechanical; ISO Couplers
REAR PTO:
540/1000 RPM, 1-3/8 In. Independent Rear PTO,
Reversible Shaft and PTO Master Shield
Electrohydraulic
Wet Multi-Disk Clutch
Neutral Start Safety System
Seat Activated PTO Warning
ROCKSHAFT, HITCH AND DRAWBAR:
Electronic Hitch
Category 2, 3-Point Hitch
Electrohydraulic Hitch Control
One Rear Fender Hitch Control
8800 Lb. Lift Capacity
LH and RH Telescopic Draft Link
Left Hand Stabilizer Bar
Category 2 Swinging Drawbar
INSTRUMENTATION:
Tachometer
Speedometer
Hour Meter
Fuel Gauge
Engine Oil Pressure Indicator Light
Coolant Temperature
PTO Engagement
Engine Air Filter Restriction Indicator
Alternator Indicator Light
Directional Indicators
Hazard Switch
CAB OPERATOR STATION:
ComfortGard Cab with Air Conditioning
and Heater
Two Doors
Front Windshield Wiper
Mechanical Suspension Seat with
Armrests and Seat Belt
Tilt/Telescopic Steering Column
Right-hand Operational Controls
Floor Mat
Foot Throttle Control
Power Outlet
Pre-Radio Wiring and Speaker Package
Overhead Courtesy Light
Rear View Mirror
ELECTRICAL:
Key Shutoff
12-Volt Electrical System
One 12-Volt Battery, 1230 Cold Cranking Amps
90 Amp Alternator
7 Terminal ASAE Outlet Socket
LIGHTS:
Two Front Grille Headlights
Two Front Roof Lights
One Rear Roof/ROPS Light
Flashing Warning Lights
Two Rear Fender Tail Lights
with Brake Lights
FRONT AXLE WHEELS AND TIRES:
MFWD
Steel Wheels
Electrohydraulic MFWD Engagement,
Right-hand Console
14.9R28 In. Radial Tires
REAR AXLE WHEELS AND TIRES:
Flanged Axle
Eight Position Steel Wheels
460/85R38 18.4R38 In. Radial Rear Tires
MISCELLANEOUS:
Operator's Manual (English) and Holder
SMV Emblem
Available for the United States, Canada, Mexico, Central America, South Korea, Israel, and Egypt Only.
CODE
ATTACHMENT
IDENTIFIER
DESCRIPTION
SUGGESTED
LIST PRICE
USD ($)
Select One Code From Each Required Category
BASE MACHINE
EX-WORKS Port of Entry
AGRICULTURAL PRODUCTS
JOHN DEERE TRACTORS
7330 Cab Tractor
Equipment for Base Machine
16 May 2012 US & Canada
2-Tractors-05300- 1
