Power Ratings
The Cutler-Hammer Liquid-Cooled product range consists of (AC input, AC output) drives.
The following tables show the drive output values for both in I
th
(current) and shaft power
(electrical) as well as the drive losses and mechanical sizes. The power achieved is given as
per the supply voltage.
Drives
Table 1-2: Power Ratings and Dimensions of Liquid-Cooled Drive, Supply Voltage
380 – 500V AC
Catalog
Number
Drive Output
Power Loss
c/a/T
(kW)
Chassis
Current Electrical Output Power
Thermal
I
th
(A)
Rated
Cont. I
L
(A)
Rated
Cont. I
H
(A)
Optimum
Motor at I
th
400V (kW)
Optimum
Motor at I
th
500V (kW)
LCX016A0-4 16 15 11 7.5 11 0.4/0.2/0.6 CH3
LCX022A0-4 22 20 15 11 15 0.5/0.2/0.7 CH3
LCX031A0-4 31 28 21 15 18.5 0.7/0.2/0.9 CH3
LCX038A0-4 38 35 25 18.5 22 0.8/0.2/1.0 CH3
LCX045A0-4 45 41 30 22 30 1.0/0.3/1.3 CH3
LCX061A0-4 61 55 41 30 37 1.3/0.3/1.5 CH3
LCX072A0-4 72 65 48 37 45 1.2/0.3/1.5 CH4
LCX087A0-4 87 79 58 45 55 1.5/0.3/1.8 CH4
LCX105A0-4 105 95 70 55 75 1.8/0.3/2.1 CH4
LCX140A0-4 140 127 93 75 90 2.3/0.3/2.6 CH4
LCX168A0-4 168 153 112 90 110 4.0/0.4/4.4 CH5
LCX205A0-4 205 186 137 110 132 5.0/0.5/5.5 CH5
LCX261A0-4 261 237 174 132 160 6.0/0.5/6.5 CH5
LCX300A0-4 300 273 200 160 200 7.0/0.6/7.6 CH61
LCX385A0-4 385 350 257 200 250 9.0/0.7/9.7 CH61
LCX460A0-4 460 418 307 250 315 6.5/0.5/7.0 CH72
LCX520A0-4 520 473 347 250 355 7.5/0.6/8.1 CH72
LCX590A0-4 590 536 393 315 400 9.0/0.7/9.7 CH72
LCX650A0-4 650 591 433 355 450 10.0/0.7/10.7 CH72
LCX730A0-4 730 664 487 400 500 12.0/0.8/12.8 CH72
