Jackson Vision Series AJ-64 - Manual (Page 6)

8"
4 1/2"
8"
4" 72"
10 1/2"
21" Opening
80"
4"w. x 16"lg cutout in
Vent Cowl/Splash Shield.
Shipped with Cover Plate.
12 1/2"
25"
64"
Table to Table
AJ-64
Approximate Total Load Amperes
Power Supply AJ-64CE AJ-64CS
208/60/1 138.9 18.8
230/60/1 127.5 18.8
208/60/3 81.8 12.3
230/60/3 75.1 12.3
460/60/3 37.6 6.2
Recommended Table Fabrication
Rack Rail Height
Above Dishtable
1/4" – 5/16"
Rack Rail
Tub
Table
Use Silicone Sealer
Between Table and
Lip of Machine to
Prevent Leakage
Tub Will Accept
a Table Flange
Up to 24 7/8"
Table Turndown
Flange 3/4" Max
3/4"
21"
Note:
Conveyors
www.jacksonwws.com
1-8 8 8-8 00-5 672
07610-002-66-79 3/13
All specifications subject to change without notice.
