Conveyors AJ-64 Vision Series
Specifications
NOTE: The AJ-64 series conveyor dishmachines are
listed by the National Sanitation Foundation (NSF),
Underwriters Laboratories Inc. (UL), and by the Canadian
Standards Association (CSA). They also meet the require-
ments of A.S.S.E. Standard No. 1004.
PERFORMANCE: Fully automatic, multiple tank,
rack conveyor dishwasher designed to wash, rinse, and
sanitize tableware and utensils commonly associated
with the preparation and consumption of food items in a
commercial foodservice operation. Sanitization is accom-
plished through hi-temp sanitization utilizing 180-195°F
fresh water rinse. The unit conveys standard 20” x 20”
dishracks through a recirculating detergent laden wash
section where 270 gallons per minute (GPM) of 150°F
wash water is pumped over the dishrack to remove the
food soil. It then enters the power rinse section where an
initial rinse of 160°F water at 270 (GPM) is pumped over
the dishrack. The rack is conveyor driven into a final
rinse section where a fresh water final rinse spray sys-
tem removes remaining residual detergent and sanitizes.
The unit must be installed to a potable water line capa-
ble of supplying 222 gallons per hour between 180-195°F
at 15-25 PSI flow pressure for maximum hourly rack
capacity of 287 racks per hour.
CONSTRUCTION: All stainless steel components
are 304 series stainless steel. No 400 series stainless
steel and/or plastics are utilized. Frame is constructed of
2” diameter stainless steel tubing formed and completely
saddle welded for superior strength. The wash and rinse
tank chambers are formed and heliarc welded 16 gauge
#2B finish. Hood is 16 gauge #3 finish. Stainless steel
feet are adjustable ±1/2”.
WASH PUMP: Internal wash pump located inside
the wash tub is totally stainless steel including the
impeller. The pump itself is totally integral with the motor
and self draining. Wash water is recirculated from the
wash tank through the manifolds and wash arm system
at the rate of 270 GPM.
WASH PUMP MOTOR: A 2 HP totally enclosed,
fan cooled type motor drives the wash pump and arms.
Single-phase motors are capacitor start, induction run
with internal thermal overload protection. Three-phase
motors are induction run with external overload protec-
tion. Motor shaft is supported by permanently lubricated
grease packed ball bearings.
POWER RINSE PUMP: Internal power rinse
pump located inside the power rinse tub is totally stain-
less steel including the impeller. The pump itself is totally
integral with the motor and self draining. Rinse water is
recirculated from the tank through the manifolds and
rinse arm system at the rate of 270 GPM.
POWER RINSE PUMP MOTOR: A 2 HP total-
ly enclosed, fan cooled type motor drives the wash pump
and arms. Single-phase motors are capacitor start,
induction run with internal thermal overload protection.
Three-phase motors are induction run with external over-
load protection. Motor shaft is supported by permanently
lubricated grease packed ball bearings.
CONVEYOR SYSTEM: Racks are conveyed
through the machine by a center-mounted, heavy-duty
stainless steel pawl bar with stainless steel cast, counter-
weighted, wide surface pawls. The pawl bar is designed
not to interfere with spray patterns in the wash, power
rinse, and final rinse sections. The pawl bar is driven by a
1/4 HP motor and worm drive gear reduction unit. The
conveyor motor itself is totally enclosed, non-ventilated.
Single-phase motors are capacitor start, induction run
with internal thermal overload protection. Three-phase
motors are induction run with external overload protec-
tion. Pawl bar conveyor drive unit is mounted on the left
hand side of the machine and is enclosed with a remov-
able stainless steel cover. Maximum conveyor speed is 8.0
feet per minute.
ADJUST-A-PEAK: The Adjust-A-Peak feature is a
mechanical feature located on the pawl bar drive unit itself
and allows the end-user to slow down the speed of the
conveyor drive unit when enhanced results are required
(i.e. baked-on food soil) or increase the speed of the con-
veyor drive unit when maximum capacity is required. By
slowing down the conveyor, a rack of tableware remains in
the prewash, wash, and rinse sections for longer periods of
time. When soil loads are heavy (i.e. pots and pans, trays,
and bun pans), adjusting the conveyor to slower speeds
means outstanding results.
CHAMBER: The chamber has a standard clearance
of 25” which is the highest clearance in the industry---
even higher than competitive higher hood options. This
adds to the versatility of the machine since you can easily
accommodate larger utensils such as sheet pans and 60
quart mixing bowls. The combination of a higher hood in
conjunction with manually slowing down the conveyor uti-
lizing the Adjust-A-Peak feature produces superior results
as well as adding to the versatility of the machine.
CONTROLS: Controls are located in a stainless steel
control box mounted on top of the machine for ease of
access and increased reliability. Power “ON/OFF” switch
is the only manual switch required. “Energy Guard” fully
automates the machine and utilizes switching logic to
operate wash, power rinse, and final rinse sections only
when a rack is being washed or rinsed. It will turn the
conveyor off when a rack exits the machine and there
are no other racks in the unit. Regardless of machine
voltage, all control circuitry will be operated from a 110
volt control circuit transformer. Again, the Adjust-A-Peak
feature eliminates the need for manual controls since you
have the ability to slow down the conveyor for extended
wash, power rinse, and final rinse contact time. The unit
is completely wired with 105°C, 600V thermoplastic insu-
lated wire and routed through UL approved conduit. The
control circuit itself is protected by a manual reset 1
AMP overload protector located on the front of the con-
trol box.
FILL: Initial fill of wash and power rinse tanks is auto-
matic when machine is initially energized. The fill line
needs to be hooked up to a 180°F minimum potable
water line which normally would be supplied by an exter-
nal booster heater or our optional Hatco booster heater
packages. Fill is controlled by a standard solenoid valve
and vacuum breaker assembly. The incoming water sole-
noids are activated by stainless steel float systems locat-
ed in the wash tank and power rinse tank for maintaining
required fill levels.
RECIRCULATING WASH: The wash tank has a
15.4 gallon capacity and maintains that level with a
skimming type overflow. Washing action is accomplished
by recirculating detergent laden water in the wash tank
through upper and lower wash arms. Make-up water
comes from the power rinse section and is controlled at
approximately 2 GPM. The wash arms are 18” long.
Wash performance commences 5” into the machine.
Wash section is automatically activated by racks as they
pass through. Wash arms, upper and lower, contain 43
separate stripping nozzles for superior performance. Both
wash arms are easily removable and along with remov-
able wash arm end caps, are easily cleanable without the
use of tools. Large stainless steel strainer pans, as well
as a pump intake strainer for secondary protection are
readily accessible and removable for cleaning purposes.
Knockouts and connections are provided to allow easy
installation of detergent concentration sensor and dis-
penser tubing by others.
POWER RINSE: The power rinse tank has a 15.4
gallon capacity and maintains that level with a skimming
type overflow. Rinsing action is accomplished by recircu-
lating final rinse water in the tank through upper and
lower wash arms. Makeup water comes from the final
rinse section and is controlled at approximately 2 GPM.
The power rinse arms are 12” long. The power rinse sec-
tion is automatically activated by racks as they pass
through. Power rinse arms, upper and lower, contain 32
separate stripping nozzles for superior performance. Both
power rinse arms are easily removable and along with
removable wash arm end caps, are easily cleanable
without the use of tools. Large stainless steel strainer
pans, as well as a pump intake strainer for secondary
protection are readily accessible and removable for
cleaning purposes.
FINAL RINSE: Fresh pressurized rinse water enters
the machine through a standard “Y” strainer, solenoid
valve, and approved vacuum breaker assembly and is
plumbed to upper and lower final rinse arms located at
the output end of the machine. A single row of fan jet
nozzles are located on both rinse arms. Connection point
is provided for rinse agent injection into the final rinse
line by others. Total final rinse flow rate is 3.7 GPM.
DRAIN, OVERFLOW, AND MAKE-UP: The
machine is designed to maintain appropriate wash and
power rinse tank water levels at all times even at low
pressures. The overflow system is designed to automati-
cally skim the surface of the wash and power rinse
tanks. Make-up water from the final rinse system replen-
ishes the wash and power rinse water, maintains water
levels as well as appropriate tank temperatures. Large
levers located on the front panel of the machine operate
valves that drain the machine completely.
PRESSURE REDUCING VALVE:
Factory installed on incoming water line to control water
pressure.
Additional Standard
Equipment:
• Vent cowls/splash shields with 4” x 16” openings covered with
removable plates for connection to exhaust ducts when required.
• Flexible NSF approved strip curtains provided at the ends of
the vent cowls as well as at the ends of the machine and sepa-
rating the wash, power rinse, and final rinse sections.
• Extra large inspection doors located on front of machine for
easy access and cleanability
• Safety door switches shut down machine should any door be
opened during operation.
• Stainless steel front appearance panel.
• Positive low level water protection for wash and power rinse
tank heat.
• Sealed dial type thermometers for the wash, power rinse and
final rinse temperatures.
Optional Mandatory
Equipment:
Wash Tank Heating Equipment
(Choose One):
ELECTRIC: Low watt density 25 KW tubular heating
elements mounted inside the tanks (15 KW wash and 10
KW power rinse) and easily removable from the outside.
The heaters are protected by a stainless steel float sys-
tem as well as high limit overload protection. Water tem-
perature in the tanks is controlled and maintained by fast
reacting thermostats which control the heating elements.
STEAM: Stainless steel coils are utilized rather than
injectors so that contaminated steam being injected into
the wash water is not an issue. Stainless steel tubular
steam coils are mounted inside the wash and power
rinse tanks below the optimum water level. The coils are
protected by a stainless steel float system. An external
steam “Y” strainer and high temperature steam solenoid
regulates the flow of steam through the coils.
Temperature in the tanks is controlled and maintained by
fast reacting thermostats which control the operation of
the steam solenoids. A float and thermostatic steam trap
is provided and removes steam condensate from the
steam coils which can either be plumbed to a drain or
pumped back to the boiler if a condensate return system
is available. Steam coils require a minimum of 10 PSIG
flowing steam supply and a maximum of 20 PSIG. Install
with a steam pressure regulator (by others) if steam
supply exceeds 20 PSIG.
Optional Features and
Accessories:
EXTERNAL ELECTRIC BOOSTER HEATER:
External 36 KW Hatco booster heater boosts incoming
140°F water to a minimum of 180°F for hi-temp sanitiz-
ing rinse. Custom features include castone-lined tank,
low water cutoff, pressure relief valve, as well as a pres-
sure reducing valve. Unit is located next to the output
end of the machine, completely preplumbed. Power to
the booster heater requires a separate electrical connec-
tion. Unless specified otherwise, electrical characteristics
of the booster heater will be the same as that of the
dishwasher. The booster heater is approximately 36 KW
and is available in 208/240/480 voltages/3 phase only.
EXTERNAL 70°F RISE BOOSTER HEATER:
External 45 KW Hatco booster heater capable of boosting
incoming 110°F water a minimum of 70 degrees to a
minimum of 180°F for hi-temp sanitizing rinse. Unit is
located next to the output end of the machine and comes
completely preplumbed. Power to the booster heater
requires a separate electrical connection. Unless speci-
fied otherwise, electrical characteristics of the booster
heater will be the same as that of the dishwasher. The
booster heater is available in 208/240/480 voltages/3
phase only.
STEAM BOOSTER HEATER: Sized to be con-
nected to a standard 140°F incoming water supply in
order to insure 180-195°F hi-temp sanitizing final rinse
requirements. Unit comes complete with steam “Y”
strainer and high temperature steam solenoid as well as
a steam pressure relief valve. Water temperature is con-
trolled and maintained by a fast reacting thermostat
which controls the operation of the steam solenoid. A
float and thermostatic steam trap is provided and
removes steam condensate from the coil which can
either be plumbed to a drain or pumped back to a boiler
if a condensate return system is available. Must be
installed with a steam pressure regulator (by others) if
steam supply exceeds 20 PSIG.
TABLE LIMIT SWITCH: Factory wired to machine
and mounted to the backsplash of the table in the field.
Prevents damage to conveyor drive system, racks, and
dishes due to racks backing up on the output end of the
machine. Highly recommended for clean dishtables less
than 10 feet in length.
VENT COWL COLLARS: Factory installed 4” x
16” x 7” high collars located on the vent cowls to allow
easy connection to an external exhaust system including
a standard “pant-leg” type exhaust duct. Includes
adjustable and lockable damper flap for fine tuning
exhaust system to remove appropriate CFM requirements.
50 CYCLE (HERTZ) ELECTRICAL
CHARACTERISTICS: Units are available in 50 HZ
in the following voltages: 208V/1 or 3PH, 230V/1 or 3PH,
380V/3PH, and 460V/3PH. Units operating at 50 HZ are
not submitted for UL Listing.
SIDELOADER: Factory installed option on input end
of conveyor machine. This feature allows the machine to
be installed close to a corner and maximize dishroom
space. The sideloader option is available in both the
hooded and unhooded versions. See separate spec sheets
for details.
EXHAUST VENT FAN CONTROL:
Automatically turns exhaust vent fan on when rack enters
the machine. Delay timer also turns off the exhaust vent
fan 5-10 seconds after rack exits machine when no other
racks are being conveyed through the machine.
FLANGED FEET: Available for installations where
permanent mounting to the floor is required. Fully
adjustable for required height.
WATER HAMMER ARRESTOR: Installed
inside the supply line.
