References
40
TH-S2
7
Center unit (XV-THS2)
Audio section
Front/Center/Surround:
45 W per channel, RMS at 6
C at 1
kHz, with 10 % total harmonic
distortion.
Subwoofer:
45 W, RMS at 6
C at 100 Hz, with10
% total harmonic distortion.
Digital input*:
OPTICAL DIGITAL IN:
–21 dBm to –15 dBm (660 nm
E30 nm)
* Corresponding to Linear PCM, Dolby Digital, and DTS Digital
Surround (with sampling frequency — 32 kHz, 44.1 kHz, 48 kHz)
Video section
Video System:
NTSC
Horizontal Resolution:
500 lines
Signal-to-Noise Ratio:
64 dB
Video output level
Composite:
1.0 V(p-p)/75
C
S-video-Y:
1.0 V(p-p)/75
C
S-video-C:
0.286 V(p-p)/75
C
Component-Y:
1.0 V(p-p)/75
C
Component-P
B
/P
R
:
0.7 V(p-p)/75
C
Tuner section
Tuning Range
FM:
87.5 MHz to 108.0 MHz
AM:
530 kHz to 1 710 kHz
General
Power Requirements:
AC 120 V
, 60 Hz
Power Consumption:
80 W (at operation)
1.0 W (in standby mode)
Dimensions (W M H M D): 360 mm M 65 mm M 370 mm
Mass:
5.3 kg
7
Front speakers (SP-THS3F)
Type:
1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker:
8.0 cm cone M 1
Power Handling Capacity: 52 W
Impedance:
6
C
Frequency Range:
85 Hz to 20 000 Hz
Sound Pressure Level:
82 dB/W
·
m
Dimensions (W M H M D): 105 mm M 118 mm M 98 mm
Mass:
0.60 kg each
7
Center speaker (SP-THS3F)
Type:
1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker:
8.0 cm cone M 1
Power Handling Capacity: 52 W
Impedance:
6
C
Frequency Range:
85 Hz to 20 000 Hz
Sound Pressure Level:
82 dB/W
·
m
Dimensions (W M H M D): 105 mm M 118 mm M 98 mm
Mass:
0.65 kg
7
Surround Speakers (SP-THS3F)
Type:
1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker:
8.0 cm cone M 1
Power Handling Capacity: 52 W
Impedance:
6
C
Frequency Range:
85 Hz to 20 000 Hz
Sound Pressure Level:
80 dB/W
·
m
Dimensions (W M H M D): 105 mm M 118 mm M 98 mm
Mass:
0.55 kg each
7
Subwoofer (SP-WS3)
Type:
1-Way Bass-Reflex Type
(Magnetically-shielded Type)
Speaker:
16 cm cone M 1
Power Handling Capacity: 52 W
Impedance:
6
C
Frequency Range:
40 Hz to 1 800 Hz
Sound Pressure Level:
85 dB/W
·
m
Dimensions (W M H M D): 139 mm M 350 mm M 408 mm
Mass:
4.0 kg
Designs & specifications are subject to change without notice.
