Standard Z-Bar Information with
Quick-Coupler and Construction Fork
624J
Tine Length 48 in. (1220 mm) 60 in. (1525 mm)
Overall Length . . . . . . . . . . . . . . . . . . . . . . . . . 26 ft. 2 in. (7967 mm) 27 ft. 2 in. (8270 mm)
Tipping Load, Straight (fork level, load
centered forward 24 in. [610 mm]
on 48-in. [1220 mm] tine and 30 in.
[762 mm] on 60-in. [1525 mm] tine) . . . . . 17,324 lb. (7858 kg)
16,357 lb. (7419 kg)
Tipping Load, 40-Degree Full Turn (fork
level, load centered forward 24 in.
[610 mm] on 48-in. [1220 mm]
tine and 30 in. [762 mm] on 60-in.
[1525 mm] tine) . . . . . . . . . . . . . . . . . . . . 14,784 lb. (6706 kg)
13,942 lb. (6324 kg)
Operating Weight. . . . . . . . . . . . . . . . . . . . . . . 31,227 lb. (14 162 kg) 31,331 lb. (14 209 kg)
High-Lift Z-Bar Information with Pin-On-Type Bucket
General Purpose General Purpose
Bucket Type/Size w/Bolt-On Edge w/Bolt-On Edge
Capacity, Heaped SAE . . . . . . . . . . . . . . . . . . . 3.5 cu. yd. (2.7 m 3 ) 3.0 cu. yd. (2.3 m 3 )
Capacity, Struck SAE . . . . . . . . . . . . . . . . . . . . 3.0 cu. yd. (2.3 m 3 ) 2.7 cu. yd. (2.1 m 3 )
Bucket Weight . . . . . . . . . . . . . . . . . . . . . . . . . 2,630 lb. (1193 kg) 2,460 lb. (1116 kg)
Bucket Width . . . . . . . . . . . . . . . . . . . . . . . . . . 105.9 in. (2690 mm) 105.9 in. (2690 mm)
Breakout Force, SAE J732C . . . . . . . . . . . . . . . 25,884 lb. (11 741 kg) 28,657 lb. (12 999 kg)
Tipping Load, Straight . . . . . . . . . . . . . . . . . . . 21,193 lb. (9613 kg) 21,543 lb. (9772 kg)
Tipping Load, 40-Degree Full Turn, SAE. . . . . . 17,998 lb. (8164 kg) 18,320 lb. (8310 kg)
Reach, 45-Degree Dump, 7-ft. (2.13 m)
Clearance . . . . . . . . . . . . . . . . . . . . . . . . . 76.4 in. (1941 mm) 74.9 in. (1903 mm)
Reach, 45-Degree Dump, Full Height. . . . . . . . 44.0 in. (1117 mm) 40.9 in. (1039 mm)
Dump Clearance, 45 Degree, Full Height . . . . . 128.0 in. (3251 mm) 131.1 in. (3330 mm)
Overall Length, Bucket on Ground . . . . . . . . . . 26 ft. 2 in. (7984 mm) 25 ft. 10 in. (7866 mm)
Loader Clearance Circle, Bucket In Carry
Position . . . . . . . . . . . . . . . . . . . . . . . . . . 40 ft. 10 in. (12 452 mm) 40 ft. 7 in. (12 375 mm)
Operating Weight. . . . . . . . . . . . . . . . . . . . . . . 31,885 lb. (14 463 kg) 31,715 lb. (14 386 kg)
Loader operating information is based on machine with standard equipment; cab; rear cast bumper/counterweight; 20.5R25 tires; ROPS cab; 175-lb. (79 kg) operator; and full fuel tank. This
information is affected by tire size, ballast, and different attachments.
Adjustments to Operating Weights for High-Lift Z-Bar with Pin-On-Type Buckets or Quick-Coupler and Hook-On-Type Buckets
Adjustments to operating weights and tipping loads for 3.5-cu.-yd. (2.7 m 3 ) general-purpose bucket with bolt-on cutting edge
Add (+) or deduct (–) lb. (kg) as indicated for Tipping Load, 40-
loaders with three-piece rims and Operating Weight Tipping Load, Straight Degree Full Turn, SAE
20.5R25 L-3 tires . . . . . . . . . . . . . . . . . . . . . . 0 lb. (0 kg) 0 lb. (0 kg) 0 lb. (0 kg)
20.5R25 L-2 tires . . . . . . . . . . . . . . . . . . . . . . – 228 lb. (– 104 kg) – 140 lb. (– 63 kg) – 120 lb. (– 54.6 kg)
20.5R25 L-3 tires . . . . . . . . . . . . . . . . . . . . . . – 64 lb. (– 29 kg) – 39 lb. (– 18 kg) – 34 lb. (– 15 kg)
20.5-25 L-2 tires. . . . . . . . . . . . . . . . . . . . . . . – 548 lb. (– 249 kg) – 161 lb. (– 73.2 kg) – 288 lb. (– 131 kg)
20.5-25 L-3 tires. . . . . . . . . . . . . . . . . . . . . . . – 416 lb. (– 189 kg) – 254 lb. (– 115 kg) – 218 lb. (– 99 kg)
600/65R25 L-3 tires** . . . . . . . . . . . . . . . . . . . + 676 lb. (+ 307 kg) + 412 lb. (+ 187 kg) + 355 lb. (+ 161 kg)
28L-26 Logger*. . . . . . . . . . . . . . . . . . . . . . . . + 835 lb. (+ 380 kg) + 511 lb. (+ 232 kg) + 440 lb. (+ 200 kg)
CaCl
2
in 20.5-25 rear tires. . . . . . . . . . . . . . . . + 1,821 lb. (+ 826 kg) + 2,221 lb. (+ 1007 kg) + 1,912 lb. (+ 867 kg)
Optional rear cast bumper/counterweight
(removed) . . . . . . . . . . . . . . . . . . . . . . . . . N/A N/A N/A
*Equipped with one-piece rims.
**CaCl
2
not recommended with 600/65R25 tires.
