Standard Z-Bar Information
with Pin-On-Type Bucket
624J
General Purpose General Purpose General Purpose w/
Bucket Type/Size w/Bolt-On Edge w/Bolt-On Edge Teeth and Segments
Capacity, Heaped SAE . . . . . . . . . . . . . . . . . . . 3.5 cu. yd. (2.7 m 3 ) 3.0 cu. yd. (2.3 m 3 ) 3.0 cu. yd. (2.3 m 3 )
Capacity, Struck SAE . . . . . . . . . . . . . . . . . . . . 3.0 cu. yd. (2.3 m 3 ) 2.5 cu. yd. (1.9 m 3 ) 2.5 cu. yd. (1.9 m 3 )
Bucket Weight . . . . . . . . . . . . . . . . . . . . . . . . . 2,630 lb. (1193 kg) 2,460 lb. (1116 kg) 2,572 lb. (1167 kg)
Bucket Width . . . . . . . . . . . . . . . . . . . . . . . . . . 105.9 in. (2690 mm) 105.9 in. (2690 mm) 105.9 in. (2690 mm)
Breakout Force, SAE J732C . . . . . . . . . . . . . . . 28,483 lb. (12 920 kg) 31,526 lb. (14 300 kg) 27,709 lb. (12 569 kg)
Tipping Load, Straight . . . . . . . . . . . . . . . . . . . 25,639 lb. (11 630 kg) 26,036 lb. (11 810 kg) 25,930 lb. (11 762 kg)
Tipping Load, 40-Degree Full Turn, SAE. . . . . . 21,854 lb. (9913 kg) 22,213 lb. (10 076 kg) 22,110 lb. (10 029 kg)
Reach, 45-Degree Dump, 7-ft. (2.13 m)
Clearance . . . . . . . . . . . . . . . . . . . . . . . . . 62.4in. (1585 mm) 60.8 in. (1543 mm) 63.5 in. (1614 mm)
Reach, 45-Degree Dump, Full Height. . . . . . . . 40.6 in. (1031 mm) 37.5 in. (952 mm) 42.0 in. (1068 mm)
Dump Clearance, 45 Degree, Full Height . . . . . 113 in. (2885 mm) 116.7 in. (2964 mm) 112.9 in. (2868 mm)
Overall Length, Bucket on Ground . . . . . . . . . . 24 ft. 10 in. (7572 mm) 24 ft. 6 in. (7452 mm) 24 ft. 11 in. (7603 mm)
Loader Clearance Circle, Bucket In Carry
Position . . . . . . . . . . . . . . . . . . . . . . . . . . 39 ft. 8 in. (12 076 mm) 39 ft. 5 in. (12 008 mm) 39 ft. 8 in. (12 095 mm)
Operating Weight. . . . . . . . . . . . . . . . . . . . . . . 31,691 lb. (14 375 kg) 31,522 lb. (14 298 kg) 31,634 lb. (14 349 kg)
Loader operating information is based on machine with standard equipment; cab; rear cast bumper/counterweight; 20.5R25 tires; ROPS cab; 175-lb. (79 kg) operator; and full fuel tank. This
information is affected by tire size, ballast, and different attachments.
Adjustments to Operating Weights for Standard Z-Bar with Pin-On-Type Buckets or Quick-Coupler and Hook-On-Type Buckets
Adjustments to operating weights and tipping loads for 3.5-cu.-yd. (2.7 m 3 ) general-purpose bucket with bolt-on cutting edge
Add (+) or deduct (–) lb. (kg) as indicated for Tipping Load, 40-
loaders with three-piece rims and Operating Weight Tipping Load, Straight Degree Full Turn, SAE
20.5 R 25 L-3 tires . . . . . . . . . . . . . . . . . . . . . 0 lb. (0 kg) 0 lb. (0 kg) 0 lb. (0 kg)
20.5 R 25 L-2 tires . . . . . . . . . . . . . . . . . . . . . – 228 lb. (– 104 kg) – 346 lb. (– 157 kg) – 136 lb. (– 62 kg)
20.5-25 L-2 tires. . . . . . . . . . . . . . . . . . . . . . . – 548 lb. (– 249 kg) – 377 lb. (– 171 kg) – 325 lb. (– 147 kg)
20.5-25 L-3 tires. . . . . . . . . . . . . . . . . . . . . . . – 416 lb. (– 189 kg) – 286 lb. (– 130 kg) – 247 lb. (– 112 kg)
600/65R25 L-3 tires** . . . . . . . . . . . . . . . . . . . + 676 lb. (+ 307 kg) + 465 lb. (+ 211 kg) + 401 lb. (+ 182 kg)
28L-26 Logger*. . . . . . . . . . . . . . . . . . . . . . . . + 835 lb. (+ 380 kg) + 576 lb. (+ 261 kg) + 497 lb. (+ 225 kg)
CaCl
2
in 20.5-25 rear tires. . . . . . . . . . . . . . . . + 1,821 lb. (+ 826 kg) + 2,502 lb. (+ 1135 kg) + 2,161 lb. (+ 980 kg)
Optional rear cast bumper/counterweight
(removed) . . . . . . . . . . . . . . . . . . . . . . . . . N/A N/A N/A
*Equipped with one-piece rims.
**CaCl
2
not recommended with 600/65R25 tires.
Standard Z-Bar Information with Quick-Coupler and Bucket
General Purpose General Purpose
Bucket Type/Size w/Bolt-On Edge w/Bolt-On Edge
Capacity, Heaped SAE . . . . . . . . . . . . . . . . . . . 3.5 cu. yd. (2.7 m 3 ) 3.0 cu. yd. (2.3 m 3 )
Capacity, Struck SAE . . . . . . . . . . . . . . . . . . . . 3.0 cu. yd. (2.3 m 3 ) 2.7 cu. yd. (2.1 m 3 )
Bucket Weight with Coupler. . . . . . . . . . . . . . . 3,522 lb. (1598 kg) 3,348 lb. (1519 kg)
Bucket Width . . . . . . . . . . . . . . . . . . . . . . . . . . 105.9 in. (2690 mm) 105.9 in. (2690 mm)
Breakout Force, SAE J732C . . . . . . . . . . . . . . . 23,455 lb. (10 637 kg) 25,633 lb. (11 625 kg)
Tipping Load, Straight . . . . . . . . . . . . . . . . . . . 23,882 lb. (10 831 kg) 24,286 lb. (11 014 kg)
Tipping Load, 40-Degree Full Turn, SAE. . . . . . 20,237 lb. (9178 kg) 20,606 lb. (9345 kg)
Reach, 45-Degree Dump, 7-ft. (2.13 m)
Clearance . . . . . . . . . . . . . . . . . . . . . . . . . 63.0 in. (1600 mm) 61.7 in. (1568 mm)
Reach, 45-Degree Dump, Full Height. . . . . . . . 45.7 in. (1161 mm) 42.6 in. (1081 mm)
Dump Clearance, 45 Degree, Full Height . . . . . 105.4 in. (2678 mm) 108.6 in. (2759 mm)
Overall Length, Bucket on Ground . . . . . . . . . . 25 ft. 10 in. (7864 mm) 25 ft. 5 in. (7744 mm)
Loader Clearance Circle, Bucket In Carry
Position . . . . . . . . . . . . . . . . . . . . . . . . . . 40 ft. 3 in. (12 258 mm) 40 ft. 0 in. (12 183 mm)
Operating Weight. . . . . . . . . . . . . . . . . . . . . . . 32,608 lb. (14 788 kg) 32,416 lb. (14 701 kg)
Loader operating information is based on machine with standard equipment; cab; rear cast bumper/counterweight; 20.5R25 tires; ROPS cab; 175-lb. (79 kg) operator; and full fuel tank. This
information is affected by tire size, ballast, and different attachments.
