Specifications

* Design and specifications subject to change without notice.

Camera head section

■

mage sensing device

: 1/3-inch IT-CCD (410,000 pixels)

■

Shooting system

: 4-CCD new dual green system

■

Colour separation optical system : 1/3 type F1.4 3-colour separation prism

■

Number of effective pixels

: 768 (horizontal) x 494 (vertical), 380,000 pixels

■

Camera output

: 19 pins

■

Lens mount

: Special mount (C mount form, flange back: 28.0 mm)

■

Dimensions

: Camera head; 59 (W) x 70 (H) x 79 (D) mm (2-3/8” x 2-13/16” x 3-1/8”)

(not including insulating rubber covers)

■

Weight

: Camera head; 230 g

(0.51 lbs.)

(not including insulating rubber covers)

■

Classification

: Type BF

Camera control unit section

■

Number of scanning lines

: 1125 (980 effective)

■

Scanning system

: 2:1 interlace

■

Scanning frequency

: 33.75 kHz (horizontal), 60 Hz (vertical)

■

Aspect ratio

: 4:3

■

Horizontal resolution (center)

: More than 800 TV lines (Y signal)

■

Vertical resolution (center)

: More than 650 TV lines (Y signal)

■

S/N

: 52 dB

■

Sensitivity

: F5.6, 2000 lx

■

Minimum subject illuminance

: 10 lx (F1.6 + 12 dB, 1/30 shutter, 50% level)

■

Sync system

: Internal sync/external sync

■

External sync signal input

: Composite video signal of 1 Vp-p or composite sync signal of ±0.3 Vp-p, 75 ohms, BNC x 1

■

Colour bar

: Full colour bar

■

Contour correction

: Horizontal dual-edged (9-step variable)

Vertical dual-edged (9-step variable)

■

Electronic shutter speed

: 1/30 s, 1/60 s (normal), 1/100 s (flicker-free), 1/175 s, 1/250 s, 1/375 s, 1/500 s, 1/1000 s,

1/2000 s

■

Video output
• R/G/B signal

: 0.7 Vp-p, 75 ohms for each (no sync), BNC connector x 3 (one for each)

• Y/P

: 1 Vp-p, 75 ohms (including sync)

: 0.7 Vp-p, 75 ohms (including sync)

• Sync signal

: HD; BNC x 1 (TTL)

VD, BNC x 1 (TTL)
C. SYNC; BNC x 1
(±0.3 Vp-p, 75 ohms, compliant with HDTV standard ITU-R Rec. 709)

■

SCSI Interface

: 50 pin mini x 2

■

Camera input

: 20 pins

■

Date indication

: Menu system

1) Year, month, day
2) Day, month, year
3) Month, day, year

■

Time indication

: Menu system,

hour: minute: second

■

Power supply

: DC 12 V, 1.3 A XLR 4 pins, AA-V112E AC power adaptor (optional)

When using this unit for medical purposes, be absolutely sure to use the
separately sold AA-V31E isolation transformer.

■

Power consumption

: 18 W

■

Operating environment

: +5°C to +35°C (41°F to 95°F), 35 – 75%

■

Allowable storage environment

: –20°C to +50°C (–4°F to 122°F), 35 – 80%

■

Dimensions

: 430 (W) x 93 (H) x 322 (D) mm

(16-15/16" x 3-11/16" x 12-11/16")
(excluding the handle for rack mounting)

■

Weight

: 4.9 kg (10.8 lbs.)

■

Accessories

: Handle set x 1

■

Supplied documentation

: Instruction manual x 1

Warrantee card x 1
Service center information x 1
