23
Connectors
1 Input/output connector on the camera head
Pin
Nos.
1
2
3
4
5
6
7
8
9
0
Signals
Clock output
GND
Control signal input
Control signal input
Sync signal input
Sync signal input
Video signal output
GND
Video signal output
GND
Pin
Nos.
q
w
e
r
t
y
u
i
o
Signals
Video signal output
GND
Video signal output
GND
15 V input
5 V input
GND
-8.5 V input
-5 V input
2 Input/output connector on the CCU
Pin
Nos.
1
2
3
4
5
6
7
8
9
0
Signals
Clock input
GND
Control signal output
Control signal output
Sync signal output
Sync signal output
Video signal input
GND
Video signal input
GND
Pin
Nos.
q
w
e
r
t
y
u
i
o
p
Signals
Video signal input
GND
Video signal input
GND
15 V output
5 V output
GND
-8.5 V output
-5 V output
NC
3 DC input connector
Pin Nos.
1
2
3
4
Signals
GND
NC
NC
+12 V input
10
1
2
9
8 19
7
18
17
6
16
5
15
14 13
4
12
11
3
1 2 3 4
17 18 19 20
10 9 8 7 6 5
16 15 14 13 12 11
1
2 3
4
