Net engine power is with standard equipment including air
cleaner, exhaust system, alternator, and cooling fan at test
conditions specified per ISO9249. No derating is required up
to 10,000-ft. (3050 m). Specifications and design subject to change without notice. Wherever applicable, specifications are in accordance with SAE standards.
Except where otherwise noted, these specifications are based on a 310SJ TMC unit with 19.5L-24-in. 10PR (R4) tubeless rear and
11L-16-in. 12PR (F3) front tires, 1.12-cu.-yd. (0.86 m
3 ) loader bucket, and 24-in. x 7.5-cu.-ft. (610 mm x 0.21 m 3 ) backhoe bucket;
and a 410J TMC unit with 19.5L-24-in. 10PR (R4) tubeless rear and 11L-16-in. 12PR (F3) front tires, 1.30-cu.-yd. (1.00 m 3 ) loader
bucket, and 24-in. x 7.5-cu.-ft. (610 mm x 0.21 m 3 ) backhoe bucket.
310SJ 410J
TMC TMC
Engine
● ●
Certified to EPA Tier 3 emissions
●
John Deere Model 4045HT054 – 4.5 liter, 94 net
peak hp (70 kW) turbocharged, isolation mounted
●
John Deere Model 4045HT054 – 4.5 liter, 98 net
peak hp (73 kW) turbocharged, isolation mounted
● ●
Vertical spin-on engine oil filter
● ●
Vertical spin-on fuel filter with water separator
● ●
Oil-to-water engine oil cooler
● ●
Antifreeze, –34°F (–37°C)
● ●
Coolant recovery tank
● ●
Serpentine belt with automatic belt tensioner
● ●
Suction-type cooling fan
● ●
Enclosed safety fan guard
▲ ▲
High ambient temperature engine cooling
● ●
Dual-element dry-type air cleaner
● ●
Muffler, under hood with curved-end exhaust
stack
▲ ▲
Chrome exhaust extension
▲ ▲
Electric ether starting aid
▲ ▲
Engine coolant heater, 1,000 watts
Powertrain
● ●
PowerShift TM transmission: Torque converter with
electrically actuated twist grip F-N-R with neutral
safety switch interlock (1st through 4th gears)
● ●
Transmission oil cooler
● ●
Vertical spin-on transmission filter
▲ ▲
Transmission remote oil-sampling port
● ●
Differential lock, electric foot-actuated
● ●
Planetary final drives
● ●
Power-assisted hydraulic service brakes (con-
form to ISO 3450): Inboard, wet multi-disc,
self-adjusting and self-equalizing
● ●
Parking/emergency brake with electric switch
control (conforms to ISO 3450): Spring applied,
hydraulically released wet multi-disc / Indepen-
dent of service brakes
● ●
Hydrostatic power steering with emergency
manual mode
▲ ▲
Non-powered front axle
● ●
Mechanical-front-wheel drive with traction
control limited-slip differential: Electric on/off
control / Sealed axle
▲ ▲
Rear wheel spacers for use with chains
▲ ▲
Full MFWD guard
Backhoe
●
Extendable dipperstick, 3-ft. 6-in. extension
●
Extendable dipperstick, 4-ft. extension
●
Heavy-duty backhoe bucket cylinder
● ●
Backhoe transport lock lever
● ●
Swing lock pin stored in operator’s station
● ●
Stabilizers with two-direction anti-drift valves
● ●
Pivoting stabilizers with reversible pads
▲
Extended (long) stabilizers with reversible pads
● ●
Less bucket, with bucket pins
▲ ▲
Standard-duty backhoe bucket with lift loops
▲ ▲
Heavy-duty backhoe bucket with lift loops
▲ ▲
Severe-duty backhoe bucket with lift loops
▲ ▲
Backhoe coupler for “C,” “D,” “E,” and “G”
Series John Deere, Case, and Cat buckets
▲ ▲
Auxiliary backhoe valve for swingers, thumbs,
etc. with auxiliary plumbing
▲ ▲
Auxiliary backhoe valve for hammers and
compactors with auxiliary plumbing
310SJ 410J
TMC TMC
Backhoe (continued)
▲ ▲
Hydraulic thumb
Loader †
● ●
Loader bucket anti-spill (settable height)
● ●
Return-to-dig feature (settable / activates from
curled or dumped bucket position)
● ●
Armrest-mounted joysticks with electric clutch
cutoff, auxiliary loader control, extendible dipper-
stick control, MFWD control (momentary), MFWD
control (permanent), proportional auxiliary back-
hoe control, and horn
▲ ▲
Auxiliary loader hydraulics with thumb-switch
control
● ●
Mini joystick for simultaneous control of loader
and backhoe
● ●
Electric bucket-level indicator
● ●
Loader boom service lock
▲ ▲
Ride control
● ●
Less bucket, with bucket pins
● ●
High-visibility loader arms
▲ ▲
Tool-carrier loader: Front loader hydraulic
quick-coupler / Parallel lift (selectable) /
Return-to-carry (selectable / height set) /
Boom-height kickout
Hydraulic System
● ●
42-gpm (159 L/min.) axial piston pump
● ●
Independent hydraulic reservoir
● ●
“O”-ring face seal connectors
● ●
6-micron vertical spin-on filter
Electrical System
● ●
12-volt system
● ●
120-amp alternator
● ●
Single battery with 190-min. reserve capacity
and 950 CCA
▲ ▲
Dual batteries with 380-min. reserve capacity
and 1,900 CCA
● ●
Positive terminal battery cover
● ●
Blade-type multi-fused circuits
● ●
By-pass start safety cover on starter
▲ ▲
Master disconnect switch
● ●
Jump/auxiliary start terminal
Lights
● ●
Additional halogen work lights (6), 32,500
candlepower each (2 front, 2 rear, and 2 side
docking)
● ●
Turn signal/flashing (2 front and 2 rear)
● ●
Rear stop and tail (2)
● ●
Rear reflectors (2)
Operator’s Station
● ●
Modular-design ROPS/FOPS cab with molded
roof (conforms to SAE J1040): Isolation mounted
● ●
Left and right access
● ●
Slip-resistant steps and ergonomically located
handholds (conform to SAE J185)
● ●
Molded floor mats
● ●
Headliner
● ●
Coat hook
● ●
12-volt outlets (2)
● ●
Built-in beverage and Thermos bottle holders
● ●
Built-in Operator’s Manual storage compart-
ment with manual
● ●
Auto-idle
● ●
Interior rearview mirror
310SJ 410J
TMC TMC
Operator’s Station (continued)
● ●
Interior front-view mirror
▲ ▲
Outside rearview mirrors
● ●
Stabilizer controls in the left armrest
● ●
Rotary-dial hand throttle
● ●
Suspended foot throttle
● ●
Tilt steering, infinitely adjustable
● ●
Horn in side console
● ●
Key start switch with electric fuel shutoff
▲ ▲
Electronic anti-theft enabled through monitor
● ●
Engine coolant temperature gauge, illuminated
electronic, with audible warning
● ●
Oil temperature gauge, illuminated electronic,
with audible warning
● ●
Fuel gauge, illuminated electronic
● ●
Digital display of engine hours, engine rpm, and
system voltage
● ●
Monitor system with audible and visual warn-
ings: Engine air restriction indicator / Low alter-
nator voltage indicator / Engine oil pressure
indicator with audible warning / Hydraulic filter
restriction indicator / Parking brake on/off indi-
cator with audible warning / Seat belt indicator /
Low brake pressure / Machine diagnostic infor-
mation via 4-pushbutton/LCD operator interface
● ●
Air suspension deluxe fabric swivel seat with
lumbar adjustment
● ●
Seat belt, 2-in., with retractor
▲ ▲
Seat belt, 3-in., with retractor
● ●
Cab: Headliner, dome light, left and right cab
doors, tinted safety glass, windshield wiper
(one rear and one front), front windshield
washer, fresh-air intake, heater/defroster/
pressurizer (40,000-Btu/hr. [11.7 kW] heater),
and 12-volt outlets (2)
▲ ▲
Air conditioner (26,000-Btu/hr. [7.6 kW] output
and CFC-free R134a refrigerant)
▲ ▲
AM/FM/weather-band radio
▲ ▲
AM/FM/weather-band radio with CD player
Overall Vehicle
● ●
One-piece unitized construction mainframe
● ●
Vehicle tie-downs (2 front and 2 rear)
● ●
Remote grease bank for front axle
● ●
Heavy-duty front bumper
▲ ▲
450-lb. (204 kg) front counterweight
▲ ▲
700-lb. (317 kg) front counterweight
▲ ▲
1,000-lb. (454 kg) front counterweight
▲ ▲
1,250-lb. (567 kg) front counterweight
▲ ▲
1,450-lb. (657 kg) front counterweight
▲ ▲
Rubber grille bumpers
● ●
Fuel tank, 41 gal. (155 L), ground-level fueling
● ●
Two-position easy-tilt hood
● ●
Extended grille frame
● ●
Removable toolbox with padlock hasp
● ●
Vandal protection for locking engine hood,
toolbox, hydraulic reservoir, and fuel tank
● ●
Reverse warning alarm
▲ ▲
Sound-reduction package
● ●
Dent-resistant full-coverage rear fenders
▲ ▲
JDLink TM wireless communication system
† See dealer for range of heavy-duty, multipurpose, and
coupler buckets and forks.
310SJ / 410J WITH TOTAL MACHINE CONTROL TM
Key: ●
Standard equipment
▲
Optional equipment *See your John Deere dealer for further information.
