410J
with
Total Machine Control TM
410J
with
Total Machine Control TM
410J
with
Total Machine Control TM
Hydraulics 410J TMC
Main Pump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pressure-compensated load-sensing (PCLS) axial piston
Pump Flow @ 2,200 rpm
Backhoe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 gpm (159 L/m)
Loader. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 gpm (159 L/m)
System Relief Pressure
Backhoe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3,625 psi (24 993 kPa)
Loader. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3,625 psi (24 993 kPa)
Backhoe Controls . . . . . . . . . . . . . . . . . . . . . . . . . TMC electrohydraulic controls standard; auxiliary functions optional
Loader Controls . . . . . . . . . . . . . . . . . . . . . . . . . . TMC electrohydraulic controls standard; auxiliary function and TMC tool carrier optional
Cylinders
Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . heat-treated, chrome-plated, polished rods; hardened-steel (replaceable bushings) pivot pins
Bore Rod Diameter Stroke
Loader Boom (2) . . . . . . . . . . . . . . . . . . . . . . . . . 3.15 in. (80 mm) 1.97 in. (50 mm) 31.10 in. (790 mm)
Tool-Carrier Option (2) . . . . . . . . . . . . . . . . . 3.54 in. (90 mm) 1.97 in. (50 mm) 26.49 in. (672.9 mm)
Loader Bucket (1) . . . . . . . . . . . . . . . . . . . . . . . . 3.54 in. (90 mm) 1.97 in. (50 mm) 29.29 in. (744 mm)
Tool-Carrier Option (1) . . . . . . . . . . . . . . . . . 3.94 in. (100 mm) 2.20 in. (56 mm) 28.73 in. (729.8 mm)
Backhoe Boom (1) . . . . . . . . . . . . . . . . . . . . . . . . 4.92 in. (125 mm) 2.48 in. (63 mm) 35.31 in. (897 mm)
Backhoe Crowd (1) . . . . . . . . . . . . . . . . . . . . . . . 4.53 in. (115 mm) 2.48 in. (63 mm) 27.49 in. (698.2 mm)
Backhoe Bucket (1) . . . . . . . . . . . . . . . . . . . . . . . 3.94 in. (100 mm) 2.48 in. (63 mm) 31.89 in. (810 mm)
Backhoe Swing (2). . . . . . . . . . . . . . . . . . . . . . . . 3.54 in. (90 mm) 1.97 in. (50 mm) 10.94 in. (278 mm)
Backhoe Extendable Dipperstick (1) . . . . . . . . . 2.76 in. (70 mm) 1.57 in. (40 mm) 47.78 in. (1214 mm)
Backhoe Stabilizer, Standard (2) . . . . . . . . . . . . 3.94 in. (100 mm) 1.97 in. (50 mm) 19.69 in. (500 mm)
Non-Powered Axle (1) . . . . . . . . . . . . . . . . . . . . . 2.76 in. (70 mm) 1.65 in. (42 mm) 8.39 in. (213 mm)
Mechanical-Front-Wheel Drive (1) . . . . . . . . . . . 2.64 in. (67 mm) 1.65 in. (42 mm) 8.27 in. (210 mm)
Electrical
Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 volt
Alternator Rating . . . . . . . . . . . . . . . . . . . . . . . . . . 120 amp
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 halogen: 2 front and 2 rear (32,500 candlepower each); turn signals and flashers 2 front and 2 rear; stop and tailights and 2 rear reflectors
Operator Station
Type (SAE J1040) . . . . . . . . . . . . . . . . . . . . . . . . . canopy, isolation mounted, ROPS/FOPS, left/right access, with molded roof
Tires/Wheels
Front Rear
Non-Powered Front Axle . . . . . . . . . . . . . . . . . . . . 11L-16 SL F-3 (12) 19.5L-24 R-4 (10)
14.5/75-16.1 SL F-3 (10) 21L-24 R-4 (10)
Mechanical-Front-Wheel Drive . . . . . . . . . . . . . . . . 12.5/80-18 I-3 (10) 19.5L-24 R-4 (10)
340/80R18 XMCL 500/70R24 XMCL
12.5/80-18 I-3 (10) 21L-24 R-4 (10)
Serviceability
Hydraulic Oil Filter, Spin-On Enclosed Replace-
able Element, Vertically Mounted . . . . . . . . . . 6-micron filtration / 1,000 service hours
Refill Capacities
Cooling System . . . . . . . . . . . . . . . . . . . . . . . . 26 qt. (25 L)
Rear Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 qt. (18 L)
Engine Oil (including vertical spin-on filter) . . . . 14 qt. (13 L)
Torque Converter and Transmission . . . . . . . . 16 qt. (15 L)
Fuel Tank (with ground-level fueling) . . . . . . . 41 gal. (155 L)
Hydraulic System . . . . . . . . . . . . . . . . . . . . . . 25 gal. (95 L)
Hydraulic Reservoir . . . . . . . . . . . . . . . . . . . . . 10.2 gal. (39 L)
Mechanical-Front-Wheel-Drive Housing
Axle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 qt. (6.5 L)
Planetary (each) . . . . . . . . . . . . . . . . . . . . 1 qt. (1 L)
See page 27 for Engine, Cooling, and Powertrain information.
