John Deere 310SJ - Manual (Page 23)

Lift capacities are over-end values in lb. (kg) according to SAE J31. Figures listed are 87% of the maximum lift force available. Base vehicle includes counterweight.
A'
B'
C'
D'
310SJ Backhoe with Standard Dipperstick
SWING PIVOT SWING PIVOT
DIPPER
LIFT
WITH
BOOM
AT 65
o
BOOM
LIFT
SWING PIVOT
DIPPER
LIFT
WITH
BOOM
AT 65
o
BOOM
LIFT
0 4 8 12 16 20
0 1 2 3 4 5 6 7
FEET
METERS
0 4 8 12 16 20
0 1 2 3 4 5 6 7
FEET
METERS
FEET
METERS
5
4
3
2
1
0
1
2
3
4
16
12
8
4
0
4
8
12
5
4
3
2
1
0
1
2
3
4
16
12
8
4
0
4
8
12
5
4
3
2
1
0
1
2
3
4
16
12
8
4
0
4
8
12
0 4 8 12 16 20
0 1 2 3 4 5 6 7
3,119 (1415)
3,119 (1415)
3,049 (1383)
2,958 (1342)
2,862 (1298)
2,771 (1257)
2,684 (1217)
2,606 (1182)
2,536 (1150)
2,484 (1127)
2,462 (1117)
2,514 (1140)
4,981
(2259)
5,078 (2303)
5,712 (2591)
4,384 (1989) 2,184 (991)
2,197 (997)
2,188 (992)
2,158 (979)
2,127 (965)
2,092 (949)
2,023 (918)
2,053 (931)
1,997 (906)
1,975 (896)
1,971 (894)
1,988 (902)
2,058 (933)
2,945 (1335)
3,155 (1431)
3,373 (1530)
3,691 (1674)
4,390 (1991)
2,674 (1213) 3,745 (1699)
3,658 (1659)
3,537 (1604)
3,406 (1545)
3,276 (1486)
3,154 (1431)
3,045 (1381)
2,945 (1336)
2,854 (1295)
2,780 (1261)
2,723 (1235)
2,732 (1239)
5,585 (2533)
6,609 (2998)
5,785 (2624)
5,664 (2569)
11,389 (5166) 8,334
(3780)
BOOM
LIFT
DIPPER
LIFT
WITH
BOOM
AT 65
o
3,306 (1500)
310SJ Backhoe with 3-ft. 6-in. (1.07 m)
Extendable Dipperstick, Retracted
310SJ Backhoe with 3-ft. 6-in. (1.07 m)
Extendable Dipperstick, Extended
For more detailed spec information and available options, log on to www.JohnDeere.com.
Loader Dimensions / Performance 310SJ
P Bucket Dump Angle (maximum) . . . . . . . . . . . . 45 deg.
Q Rollback Angle at Ground Level . . . . . . . . . . . . 40 deg.
Heavy-duty Heavy-duty Heavy-duty long lip Heavy-duty Multipurpose Multipurpose
Bucket Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.00 cu. yd. 1.12 cu. yd. 1.25 cu. yd. 1.31 cu. yd. 1.25 cu. yd. 1.31 cu. yd.
(0.77 m 3 ) (0.86 m 3 ) (0.96 m 3 ) (1.00 m 3 ) (0.96 m 3 ) (1.00 m 3 )
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86 in. (2184 mm) 86 in. (2184 mm) 86 in. (2184 mm) 92 in. (2337 mm) 86 in. (2184 mm) 92 in. (2337 mm)
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 800 lb. (363 kg) 860 lb. (390 kg) 892 lb. (405 kg) 1,148 lb. (521 kg) 1,750 lb. (795 kg) 1,800 lb. (817 kg)
Breakout Force . . . . . . . . . . . . . . . . . . . . . . . . . . . 11,160 lb. (49.6 kN) 11,051 lb. (49.2 kN) 10,210 lb. (45.4 kN) 10,300 lb. (45.8 kN) 9,700 lb. (43.1 kN) 9,650 lb. (42.9 kN)
Lift Capacity (full height) . . . . . . . . . . . . . . . . . . . . 7,419 lb. (3368 kg) 7,353 lb. (3338 kg) 7,340 lb. (3332 kg) 7,200 lb. (3269 kg) 6,700 lb. (3042 kg) 6,600 lb. (2996 kg)
R Height to Bucket Hinge Pin (maximum) . . . . . . . 11 ft. 2 in. (3.40 m) 11 ft. 2 in. (3.40 m) 11 ft. 2 in. (3.40 m) 11 ft. 2 in. (3.40 m) 11 ft. 2 in. (3.40 m) 11 ft. 2 in. (3.40 m)
S Dump Clearance (bucket at 45 deg.) . . . . . . . . . 8 ft. 10 in. (2.69 m) 8 ft. 10 in. (2.69 m) 8 ft. 2 in. (2.48 m) 8 ft. 8 in. (2.64 m) 8 ft. 7 in. (2.62 m) 8 ft. 7 in. (2.62 m)
T Reach at Full Height (bucket at 45 deg.) . . . . . . 30.9 in. (785 mm) 30.2 in. (767 mm) 35.9 in. (911 mm) 30.1 in. (765 mm) 32.2 in. (818 mm) 32.2 in. (818 mm)
U Digging Depth Below Ground (bucket level) . . . . 6.3 in. (160 mm) 6.9 in. (175 mm) 5.8 in. (147 mm) 8.1 in. (206 mm) 7.3 in. (185 mm) 7.3 in. (185 mm)
V Length From Front Axle Centerline to
Bucket Cutting Edge . . . . . . . . . . . . . . . . . . . . . 6 ft. 8 in. (2.03 m) 6 ft. 8 in. (2.03 m) 7 ft. 2 in. (2.18 m) 6 ft. 8 in. (2.03 m) 7 ft. 3 in. (2.20 m) 7 ft. 1 in. (2.15 m)
Lift Capacity with Quick-Coupler / Forks
Hydraulic Capacity . . . . . . . . . . . . . . . . . . . . . . . . 48-in. (1219 mm) tines 60-in. (1524 mm) tines
A' Maximum Height. . . . . . . . . . . . . . . . . . . . . . . . 4,570 lb. (2073 kg) 4,170 lb. (1891 kg)
B' Maximum Reach . . . . . . . . . . . . . . . . . . . . . . . . 6,971 lb. (3162 kg) 6,621 lb. (3003 kg)
C' At Ground Line . . . . . . . . . . . . . . . . . . . . . . . . . 9,138 lb. (4145 kg) 8,561 lb. (3883 kg)
D' Below Ground Line . . . . . . . . . . . . . . . . . . . . . . 8.3 in. (211 mm) 8.3 in. (211 mm)
