43
OPTICAL DIGITAL OUTPUT Signals
* While playing some DVDs, digital signals may be emitted at 20 bits or 24 bits (at their original bit rate) through the OPTICAL
DIGITAL OUTPUT terminal if the discs are not copy-protected.
DIGITAL AUDIO
OUTPUT Output Signals
Playback disc STREAM/PCM DOLBY DIGITAL/PCM PCM ONLY
DVD Video
with 48 kHz, 16/20/24 bit Linear PCM 48 kHz, 16 bit Linear PCM*
with 96 kHz, Linear PCM 48 kHz, 16 bit Linear PCM
with Dolby Digital Dolby Digital bitstream 48 kHz, 16 bit Linear PCM
with DTS DTS bitstream 48 kHz, 16 bit Linear PCM
DVD-VR format discs
with 48 kHz, 16/20/24 bit Linear PCM 48 kHz, 16 bit Linear PCM*
with Dolby Digital Dolby Digital bitstream 48 kHz, 16 bit Linear PCM
SVCD, VCD, CD 44.1 kHz, 16 bit Linear PCM/48 kHz, 16 bit Linear PCM
CD with DTS DTS bitstream 44.1 kHz, 16 bit Linear PCM
MP3/WMA/MPEG-1/MPEG-2 disc 32/44.1/48 kHz, 16 bit Linear PCM
