JPX-300 Installation/Operation Manual 7610-002-71-26 Rev. J
Issued: 03-09-2006 Revised: N/A
2
SECTION 1: SPECIFICATION INFORMATION
SPECIFICATIONS of the JPX-300H/JPX-300HC/JPX-300HN
PERFORMANCE/CAPABILITIES
OPERATING CAPACITY (RACKS/HOUR)
RACKS PER HOUR
30
DISHES PER HOUR
600
GLASSES PER HOUR
600
OPERATING CYCLE (SECONDS)
WASH TIME
82
DRAIN TIME
28
RINSE TIME
10
TOTAL CYCLE TIME (MINUTES)
2
5 MINUTE TIMER OPERATING CYCLE (SECONDS)
WASH TIME
262
DRAIN TIME
28
RINSE TIME
10
TOTAL CYCLE TIME (MINUTES)
5
TANK CAPACITY (LITERS) (GALLONS)
WASH TANK (21.5) 5.65
RINSE TANK (11.4) 3
TEMPERATURES
WASH--- (MINIMUM) (65.6°C) 150°F
RINSE---(MINIMUM) (82.2°C) 180°F
WATER REQUIREMENTS
INLET TEMPERATURE
(40°F Rise Booster Heater)
(60°C) 140°F
INLET TEMPERATURE
(70°F Rise Booster Heater)
(43.3°C) 110°F
INLET TEMPERATURE (JPX-300HN)
(82.2°C)180°F
WATER LINE SIZE I.P.S. (MINIMUM)
1/2”
DRAIN LINE SIZE I.P.S. (MINIMUM)
1 1/2”
FLOW PRESSURE P.S.I.
20
±5
ELECTRICAL REQUIREMENTS
WASH MOTOR HP
3/4
NOTE: Typical Electrical Circuit is based upon (1) 125% of the
full amperage load of the machine and (2) typical fixed-trip cir-
cuit breaker sizes as listed in the NEC 2002 Edition. Local
codes may require more stringent protection than what is dis-
played here. Always verify with your electrical service con-
tractor that your circuit protection is adequate and meets all
applicable national and local codes. These numbers are pro-
vided in this manual simply for reference and may change
without notice at any given time.
JPX-300H/JPX-300HC:
RINSE
TYPICAL
HEATER
TOTAL
ELECTRICAL
VOLTS
PH
HZ
RATINGS
AMPS
CIRCUIT
208
1
50
8.2KW @ 230V
40 A
50 AMP
208
1
50
10KW @ 230V
47 A
60 AMP
230
1
50
8.2KW @ 230V
47 A
60 AMP
230
1
50
10KW @ 230V
51 A
70 AMP
208
1
60
8.2KW @ 230V
39 A
50 AMP
208
1
60
10KW @ 230V
42 A
60 AMP
230
1
60
8.2KW @ 230V
46 A
60 AMP
230
1
60
10KW @ 230V
50 A
70 AMP
460
3
60
8.2KW@480V
11 A
15 AMP
460
3
60
10KW @480V
14 A
20 AMP
JPX-300HN:
RINSE
TYPICAL
HEATER
TOTAL
ELECTRICAL
VOLTS
PH
HZ
RATINGS
AMPS
CIRCUIT
208
1
50
N/A
12 A
15 AMP
230
1
50
N/A
12 A
15 AMP
115
1
60
N/A
24 A
30 AMP
208
1
60
N/A
11 A
15 AMP
230
1
60
N/A
12 A
15 AMP
NOTE: Always refer to the machine data plate for specific
electrical and water requirements. The material provided on
this page is for reference only and may be subject to change
without notice.
