Jackson JPX-300H User Manual
Page 6
TABLE OF CONTENTS
iii
SECTION
DESCRIPTION
PAGE
I.
SPECIFICATION INFORMATION
Specifications JPX-300H/HC/HN
2
Specifications JPX-300L
3
Dimensions JPX-300H/HC
4
Dimensions JPX-300HN
5
Dimensions JPX-300L
6
II.
INSTALLATION/OPERATION INSTRUCTIONS
Installation Instructions
8
Electrical Installation Instructions
9
Chemical Dispensing Equipment
10
Programming Instructions for Chemical Feeder Pumps
11
Detergent Control
12
Operation Instructions
13
III.
PREVENTATIVE MAINTENANCE
Preventative Maintenance
16
IV.
SCHEMATICS
JPX-300HN 115 V, 60 HZ, single phase
18
JPX-300HN (Stainless Steel Switches) 115 V, 60 HZ, single phase
19
JPX-300HN (Univeral Timer & SS Switches) 115 V, 60 HZ, single phase
20
JPX-300H/JPX-300HN 208 - 240 V, 60 HZ, single phase
21
JPX-300H/JPX-300HN (Stainless Steel Switches) 208 - 240 V, 60 HZ, single phase
22
JPX-300H/JPX-300HN (S/S Switches & Contactor) 208 - 240 V, 60 HZ, single phase
23
JPX-300H/JPX-300HN (Univeral Timer & SS Switches) 208 - 240 V, 60 HZ, single phase
24
JPX-300H/JPX-300HN 460 V, 60 HZ, three phase
25
JPX-300H/JPX-300HN (Stainless Steel Switches) 460 V, 60 HZ, three phase
26
JPX-300H/JPX-300HN (Univeral Timer & SS Switches) 460 V, 60 HZ, three phase
27
JPX-300H/JPX-300HN-Extended Wash 460 V, 60 HZ, three phase
28
JPX-300H/JPX-300HN-Extended Wash (Stainless Steel Switches) 460 V, 60 HZ, three phase
29
JPX-300HC 208 - 240 V, 60 HZ, single phase
30
JPX-300HC (Stainless Steel Switches) 208 - 240 V, 60 HZ, single phase
31
JPX-300HC (Univeral Timer & SS Switches) 208 - 240 V, 60 HZ, single phase
32
JPX-300L 115 V, 60 HZ, single phase
33
JPX-300L (Stainless Steel Switches) 115 V, 60 HZ, single phase
34
JPX-300L (Univeral Timer & SS Switches) 115 V, 60 HZ, single phase
35
JPX-300L (Universal Timer & SS Switches) 208 - 240 V, 60 HZ, single phase
36
V.
JACKSON MAINTENANCE & REPAIR CENTERS
38
