Page 11
J-400 Series
5.0 General electrical safety Instructions
Your new Jacuzzi® spa is equipped with the J-1000™
system. It contains the most advanced safety and self-
protective equipment in the industry. Nonetheless, this spa
must be installed properly to ensure dependable usage.
Please contact your local Jacuzzi dealer or local building
department should you have any questions regarding your installation.
Proper grounding is extremely important. Jacuzzi spas are equipped with
a current collector system. A pressure wire connector is provided on the
surface of the control box, located inside the equipment door (Figure
B, page 13) to permit connection of a bonding wire between this point
and any ground metal equipment, metal water pipe or conduit within 5
feet (1.5m) of the spa, or copper clad grounding rod buried within 5 feet
(1.5m) of the spa. Bonding wire must be at least No. 8 AWG (8.4 mm²)
solid copper wire. This is a most important safety assurance feature.
Before installing your spa, check with your local building department to
ensure installation conforms to local building codes.
6.0 electrical Installation Instructions (240V service)
ImPOrTanT nOTICe: The electrical wiring of this spa must meet
the requirements of the National Electrical Code/USA (NEC) and any
applicable state or local codes. The electrical circuit must be installed
by a qualified electrician and approved by a local building/electrical
inspection authority.
1.
! DanGer:
to DeCrease the risk oF shoCk,
PrODuCT DamaGe Or eleCTrICal FIre.
This spa must be permanently connected (hard-wired) to the power
supply. no plug-in connections or extension cords are to be
used in conjunction with the operation of this spa. Supplying power
to the spa which is not in accordance with these instructions will void
both the independent testing agency listing and the manufacturer’s
warranty.
2. The power supplied to this spa must be a dedicated circuit with no other
appliances or lights sharing the power provided by the circuit.
3. To determine the current, voltage and wire size required, refer to section
7.0 “Power Requirements” (page 14) for your specific spa model.
Wire size must be appropriate per NEC and/or local codes.
•
We recommend type THHN wire. •
