OPERATIONS ON S-VHS DECK
Basic Playback
A
Load a cassette.
Make sure the window side is up, the rear label side is
facing you and the arrow on the front of the cassette is
pointed toward the unit.
● Do not apply too much pressure when inserting.
● If the record safety tab has been removed, playback begins
automatically.
● The unit’s power comes on automatically and the counter is
reset to 0:00:00.
B
Select the S-VHS deck.
On the unit
Press S-VHS/DVD repeatedly so that the S-VHS indicator
lights up.
On the remote control
Press S-VHS so that the S-VHS indicator lights up.
C
Find the programme start point.
If the tape is advanced past the start point, press 3. To
go forward, press 5.
D
Start playback.
Press 4. “bESt” appears blinking on the front display
panel during automatic tracking. (
੬
pg. 29)
E
Stop playback.
Press 8. Then press x on the S-VHS deck to remove the
cassette.
● Turn on the TV and select the video channel (or AV
mode).
● Slide the TV/S-VHS/DVD switch to the right.
Clean the video heads using a dry cleaning
cassette — ECL-3F — when:
● Rough, poor picture appears while a tape is played back.
● The picture is unclear or no picture appears.
● “USE CLEANING CASSETTE” appears on the screen (only
with “O.S.D.” set to “ON”). (
੬
pg. 72)
NOTE:
The heads get dirty in the following cases:
● in an environment prone to extreme temperature or
humidity
● in a dusty environment
● flaw, dirt or mold on video tapes
● continuous usage for a long time
Usable cassettes
● Compact VHS camcorder recordings can be played on this
unit. Simply place the recorded cassette into a VHS
Cassette Adapter and it can be used just like any full-sized
VHS cassette.
● This unit can record on regular VHS and Super VHS
cassettes. While only VHS signals can be recorded on
regular VHS cassettes*, both VHS and Super VHS signals
can be recorded and played back using Super VHS
cassettes.
* By using the S-VHS ET function, it is possible to record and
play back with S-VHS picture quality on VHS cassettes with
this unit.
