21
Type : LCCS video monitor
Color System : NTSC/PAL
RF Reception : U.S.A.
Channels VHF: 2 – 13, UHF: 14 – 69
Picture Tube : 4.5" measured diagonally, black
and white
Effective Screen
Size
: Width : 3-3/4" (94.2 mm)
Height : 2-13/16" (70.7 mm)
Diagonal : 4-1/2" (114.3 mm)
Video Inputs : 2 line inputs, composite video,
BNC connector x 4, 1 V(p-p),
75
Ω
Bridge connection possible,
75
Ω auto termination
Audio Inputs : 2 line inputs, monaural,
RCA-pin connector x 2,
0.5 V (rms) high-impedance
REMOTE IN
Input
: 1 line input, minijack connector
Built-in Speaker : 2" (5 cm) round x 1, 0.2 W
output
Antenna
Terminals
: VHF/UHF compatible, 75 Ω ,
F connector
Environmental
Conditions
: Operating temperature:
0°C – 40°C (32°F – 104°F)
Operating humidity: 20% – 80%
(non-condensing)
Power
Requirements
: 100 V AC – 240 V AC 50 Hz/
60 Hz or 12 V DC
Power
Consumption
: 2 A (DC 19 V) (using an AC
adapter)
3.8 A (DC 12 V) (using a
battery)
Weight : 8.0 lbs. (3.6 k ˝ ) (including AC
adapter)
7.3 lbs. (3.3 k
˝ ) (not including
AC adapter)
Dimensions
(W x H x D)
: 5-3/4" x 7-1/4" x 11-1/2"
(146 mm x 181.3 mm x 291.8 mm)
* Including AC adapter, carrying
handle, feet and stand (stored)
(power cord not included)
Provided
Accessories
: AC power cord [5.91 ft (1.8 m)]
x 1
AC adapter [model: ADP-50VB
REV. D] (attached to monitor)
x 1
SPECIFICATIONS
* Dimensions and weight are approximate.
* E. & O.E. Design and specifications are subject
to change without notice.
* Illustrations used in this manual have been
exaggerated, abbreviated or compounded for
explanatory purposes only. The appearance of
the actual product may differ slightly.
Notes about Magnets
● DO NOT place the following close to the
monitor: magnets, speakers, electric clocks,
devices or toys which use a magnet, medical
devices which use a magnet, or any other
products which generate a magnetic field.
Doing so may cause the picture to be
distorted by their magnetic effect. Also, DO
NOT place the monitor close to a high-voltage
power line or transformer.
● If an external speaker is placed close to the
monitor, the picture may be distorted. In this
case, use a shielded speaker.
