Vm9311ts, Media module – Jensen vm9311ts User Manual
Page 36
32
VM9311TS
Head
Unit
V
ideo
Out
XM
Audio
Left
XM
Audio
Right
XM
Control
Data
iPod
Media Module
*
**
Cable del jLink de iPod (vendido por separado)
iPod Nano
iPod Mini
iPod
iPod Video
DIGRAMA CABLEADO - MÓDULO DE LOS MEDIOS
*Cables de TERK XMDJEN100 (vendidos por separado)
**TERK XMD1000 dirigen el sintonizador y la antena
(vendidos por separado)
