VM9311TS

CONTROLS AND INDICATORS

Button Operation

1. OPEN

Press to activate the automatic mechanical system and move
the TFT monitor into viewing position. Press again to close
the TFT.

2. WIDE/

PIC

Press to adjust the display aspect of the picture to one of
three settings: Cinema, Normal or OFF. Press and hold to
access picture settings.

3. (

)

Press to adjust the upward tilt angle of the screen one step at
a time. Press and hold this button to continuously adjust the
upward tilt or picture settings.

4. (

)

Press to adjust the downward tilt angle of the screen one step
at a time. Press and hold this button to continuously adjust
the downward tilt or picture settings.

5. DISP

Press to display system information on the screen.

6. VOL/LO/DX

Rotate to adjust the volume. Press and release to enter and/
or confirm audio settings. Press and hold to activate the Local
(LOC) setting.

7. POWER/MUTE

Press once to turn the unit on. Press again to mute the
volume. Press and hold to turn the unit off.

NOTE: The VM9311TS features Softmute, which

will allow the volume to increase or decrease

gradually when the MUTE function is activated or

deactivated.

8. 1/AUDIO

DVD Mode: Press to select audio language during playback.

TUNER Mode: Press once to play preset radio station
channel 1. Press and hold to store the current radio station in
preset channel 1.

9. 2/SUBTITLE

DVD Mode: Press once to select the subtitle language during
playback.

TUNER Mode: Press once to play preset radio station
channel 2. Press and hold to store the current radio station in
preset channel 2.

SRC

ENTER

BAND

DISP

CLOSE

7-INCH LCD TFT

LO/DX

POWER

EJECT

VM9311TS

Push

24-bit / 192KHz DAC

AUDIO VIDEO INPUT

160 WATTS

WIDE

PIC
