Jackson 10A User Manual
Page 5
iii
TABLE OF CONTENTS
SECTION
DESCRIPTION
PAGE
I.
SPECIFICATION INFORMATION
Operating & Electrical Requirements
2
10A Dimensions
3
10AB/10APRB/10U Dimensions
4
Table Dimensions
5
II.
INSTALLATION/OPERATION INSTRUCTIONS
Visual Inspection/Unpacking the Dishmachine
7
Leveling the Dishmachine/Installing the Vacuum Breaker & Plumbing
8
Installing the Internal Vacuum Breaker/Hood Assembly
9
Plumbing the Dishmachine/Drain Line Connection/Electrical Connection
10
Final Check
11
Operation Instructions
12
Detergent Control
13
III.
PREVENTATIVE MAINTENANCE
Preventative Maintenance
15
IV.
ELECTRICAL SCHEMATICS
10A 208 - 220 V, 60 HZ, single phase
17
10AB 208 - 220 V, 60 HZ, single phase
17
10AB/10U 208 - 220 V, 60 HZ, three phase
17
10AB/APRB/10U 208 - 220 V, 60 HZ, single phase
17
10AB/APRB/10U 208 - 220 V, 60 HZ, three phase
17
WIRING DIAGRAMS
10A/10U 208 - 220 V, 60 HZ, single phase
18
10AB/10U 208 - 220 V, 60 HZ, single phase
19
10AB/10U 208 - 220 V, 60 HZ, three phase
20
10AB/APRB/10U 208 - 220 V, 60 HZ, single phase
21
10AB/APRB/10U 208 - 220 V, 60 HZ, three phase
22
V.
JACKSON MAINTENANCE & REPAIR CENTERS
24
