INDEX
35
SPECIFICATIONS
Power : AC 120 V `, 60 Hz
Power consumption
During printing : Approx. 74 W
When idle : Approx. 13 W
Signal : NTSC standard
Print format : Sublimation dye thermal
transfer line printing
Print quality
Resolution : 704 (horiz.) x 464 (vert.)
dots
Gradation : 256 tones
Print medium
Ink sheet : Cartridge
(dedicated) 3-color consecutive
printing
(yellow, magenta, cyan)
Print sheet : Paper size 150 x 100 mm
(dedicated) Print area 103 x 79 mm
Connectors
S-Video input : S-connector
(front x 1, rear x 1)
Normal video input : Pin jack (RCA connector)
(front x 1, rear x 1)
(1.0 V p – p, 75
Ω
unbalanced)
Normal output : Pin jack (RCA connector)
(Rear x 1)
(1.0 V p – p, 75
Ω
unbalanced)
Remote pause : φ 3.5 mm Mini jack
(bipolar)
JLIP :
φ
3.5 mm Mini jack
(four poles)
Operating temperature : +5 — +35°C
(+41 — +95°F)
Operating humidity : 35 — 80%
Storage temperature : –20 — +60°C
(–4 — +140°F)
Operating position : Level (horizontal) ±5°
Dimensions : 200 W x 116 H x
280 D mm
(7-7/8” x 4-5/8” x 11-1/16”)
Weight : Approx. 3.4 kg (7.5 lbs)
Provided accessories : Print sheet set VU-PS50U
(standard print paper and
ink sheet cartridge)
Conversion plug
• Design and specifications subject to change
without notice.
C
Content ...........................................
੬
pg. 16
E
Editing Index ...................................
੬
pg. 30
Error Message ..................................
੬
pg. 32
I
ID Number ......................................
੬
pg. 16
Ink Sheet Cartridge ..........................
੬
pg. 10
Inset Image ......................................
੬
pg. 22
Inset Print ........................................
੬
pg. 22
M
Main Image .....................................
੬
pg. 22
Mode Select Menu ..........................
੬
pg. 27
Motor Drive ....................................
੬
pg. 29
Multi-Print (Different Scenes) ..........
੬
pg. 20
Multi-Print (Same Scene) .................
੬
pg. 18
N
No. Of Scenes .................................
੬
pg. 18
P
Paper Jam ........................................
੬
pg. 34
Paper Sheet Set ...............................
੬
pg. 11
PIX STABILIZER ...............................
੬
pg. 16
Print Menu ......................................
੬
pg. 13
Print Sheet .......................................
੬
pg. 11
Protective Clip ................................
੬
pg. 10
S
Snapshot Print .................................
੬
pg. 28
Snapshot Search ..............................
੬
pg. 28
Stored Image ...................................
੬
pg. 15
Strobe Print .....................................
੬
pg. 24
Strobe Speed ...................................
੬
pg. 16
T
Thermal Heads ................................
੬
pg. 10
Title Impose Print ............................
੬
pg. 26
