Connecting front panel headers – Intel D845PESV User Manual
Page 30
Intel Desktop Board D845PESV Product Guide
30
Connecting Front Panel Headers
Figure 10 shows the location of the front panel headers.
OM14736
1
3
5
7
2
4
6
8
10
B
1
3
5
7
2
4
6
10
A
9
On
Reset
HD LED
Power LED
No Connection
2
1
C
1
3
D
Item Description
A
Front panel audio
B
Front panel USB 2.0
C Front
panel
D
Alternate power/sleep LED
Figure 10. Front Panel Headers
