Installing and removing the desktop board – Intel D845PESV User Manual
Page 23
Installing and Replacing Desktop Board Components
23
Installing and Removing the Desktop Board
Refer to your chassis manual for instructions on installing and removing the Intel desktop board.
WARNING
Only qualified technical personnel should do this procedure. Disconnect the computer from its
power source before performing the procedures described here. Failure to disconnect the power
before you open the computer can result in personal injury or equipment damage.
✏
NOTES
Refer to Appendix B for regulatory requirements and installation instructions and precautions.
Figure 4 shows the location of the eight mounting holes for Desktop Board D845PESV.
OM14724
Figure 4. Desktop Board Mounting Holes
