Page 29
23
5
BATTERY CHARGING
5
ï AD-106 installation
q Install the AD-106 desktop charger adapter into the holder space
of the BC-119N/121N.
w Connect the plugs of the BC-119N/BC-121N to the AD-106 with
the connector, then install the adapter into the charger with the
supplied screws.
Desktop charger adapter
Connectors
Plugs
Screws supplied
with the charger
adapter
