6
2
PANEL DESCRIPTION
■ Front, top and side panels
q CHANNEL SW/SELECTOR
• IC-F14S/F24S : Toggle the channel switch to select the
pre-programmed channel 1 or 2.
• IC-F14/F24/F26-L : Rotate the channel selector to select the
pre-programmed memory channels.
w VOLUME CONTROL [VOL]
Rotate to turn the power ON/OFF and adjust the audio level.
r
q
w
y
u
i
e
Microphone
Speaker
t
IC-F14S/F24S IC-F14/F24/F26-L
IC-F14_F24-6.qxd 06.9.29 6:09 PM Page 6 (1,1)
