13
8xC251Tx Hardware Description
Table 13
shows the effect of programming EDF# and WSB#[1:0] on the extended data float timing feature as
well as the insertion of wait states for region 01:. It should be noted that enabling the extended data float
timing allows region 01: to have 1 or 3 wait states inserted (depending on WSB#[1:0]) but not 0 or 2 wait
states.
The external user configuration cycle (UCONF = 1 and EA# = 0) will be executed with the extended TRHDZ1
timing bus cycle.
Table 13. Summary of the EDF# and WSB#[1:0] Configuration Options
EDF#
WSB#[1:0]
Wait State
Extended Data Float
Timings
1
11
0
No
1
10
1
No
1
01
2
No
1
00
3
No
0
11
1
Yes
0
10
1
Yes
0
01
3
Yes
0
00
3
Yes
