Torso Support
Item
Number Part Number Description Note
Quantity Per
Package Assembly
88804529X040 Pad, Headrest 1 1 1 B
60284X001 Screw, Socket Head (1/4-20 x 1/2") 1 1 2
88804529X043 Cover Torso Bracket 1 1 3
03018X043 Bracket, Clamp, Chrome - Right 1 1 4
03018X046 Bracket, Clamp, Chrome - Left 1 1 4
03018X041 Bracket, Pad Support, Chrome 1 1 5
11232X009 Bolt, Lug (5/16-24 x 1-3/8") 1 1 6
7930363 Package, Locknut (5/16"-24) 25 1 7
03018X016 Bracket, Support, Chrome 1 1 8
7930360 Package, Screw, Phillips Pan Head (#10-32 x
11/16") 25 1 9
03018X012 NLA - Rod, Support w/ Guide Tube 1 1 10
8881050189 Torso Support Assembly (Pair) 1 1 11 B,D
8881050190 Torso Support Assembly (Pair) 1 1 11 B,C
1023610 Instruction Sheet 1 1 A
A - Not Shown
B - Specify upholstery color, see page titled "Packaging and Upholstery Colors".
C - Recliner
D - Non-Recliner NOTE:
66
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 88-139
