Legrest Support Assembly
92 - (12', 14", 16" Wide Chairs)
Calf Pads are not included with support assembly. Please refer to "Front Riggings Index and Calf Pads"
category.
Item
Number
Part Number
Description
Note
Quantity Per
Package Assembly
47352X003
Lock, Pad Plate, Legrest, Chrome
1
1
1
47352X004
Clamp
1
1
2
04526X006
Tube, Elevating Support, Chrome - Right
1
1
3
F
04526X007
Tube, Elevating Support, Chrome - Left
1
1
3
F
04526X002
Tube, Support, Legrest, Elevating, Chrome - Right
1
1
3
G
04526X003
Tube, Support, Legrest, Elevating, Chrome - Left
1
1
3
G
04526X004-NLA NLA - Tube, Elevating Support, Chrome - Right
1
1
3
H
04526X005-NLA NLA - Tube, Elevating Support, Chrome - Left
1
1
3
H
1046328
Kit, Ratchet
1
1
4
A,E
42326X001
Bar, Ratchet
1
1
5
1037126
Handle, Release
1
1
6
A
1040060
Tip, Plastic, Black
1
1
7
C
1006490
Tip, Plastic, Black
1
1
7
D
04528X002
Bracket, Release, Chrome
1
1
8
A
1040831
Ring, Snap
1
1
9
B,C
40187X000
Pin, Roll (1/8" x 9/16")
1
1
9
B,D
7930310
Washer, Nylon (5/16 x 11/16 x 1/16")
25
1
10
1037485
Spring, Release
1
1
11
A
1037125
Cam, Legrest
1
1
12
A
7930336
Nut, Acorn (5/16-24)
25
1
13
11919X000
NLA - Screw, Slotted Truss Head (3/8-16 x 1-1/2")
1
1
14
1031481
Legrest Support Tube Assembly, Adult, Chrome -
Right
1
1
15
1031482
Legrest Support Tube Assembly, Adult, Chrome -
Left
1
1
15
47330X003
Spacer (5/16 x 1/2 x 3/8")
1
1
16
11232X009
Bolt, Lug (5/16-24 x 1-3/8")
1
1
17
1027095
Plug Button, Black (7/8")
1
1
18
40363X000
Hex Nut (3/8"-16)
1
1
19
1107321
Nut, Low Cap (5/16"-24)
1
1
20
1022874
Bumper
1
1
21
1030979
Screw, Phillips Pan Head Tap (#10-32 x 3/4")
1
1
22
1031485
Legrest Support Assembly, Adult, Silver Vein -
Right
1
1
23
C,F
1031486
Legrest Support Assembly, Adult, Silver Vein - Left
1
1
23
C,F
1031487
Legrest Support Assembly, Adult, Silver Vein -
Right
1
1
23
D,G
1031488
Legrest Support Assembly, Adult, Silver Vein - Left
1
1
23
D,G
1031483-NLA
NLA - Legrest Support Assembly, Adult, Chrome -
Right
1
1
23
H
1031484
Legrest Support Assembly, Adult, Chrome - Left
1
1
23
H
See Chart
Pivot Slide Tube with Aluminum Footplate
1
1
I
46
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 88-139
