Footrest Support Assembly
93J
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1006490 Tip, Plastic, Black 1 1 1 A
7930360 Package, Screw, Phillips Pan Head (#10-32 x
11/16") 25 1 2
7930359 Package, Screw, Phillips Pan Head (#10-32 x 1/2") 25 1 3
1027095 Plug Button, Black (7/8") 1 1 4
1008935 Spring, Release - Right 1 1 5
1008936 Spring, Release - Left 1 1 5
04706X039-NLA NLA - Tube, Footrest Support, Adult, Chrome -
Right
1 1 6
04706X040-NLA NLA - Tube, Footrest Support, Adult, Chrome - Left 1 1 6
67005X000 Rivnut (#10-32) 1 1 7
7930363 Package, Locknut (5/16"-24) 25 1 8
11232X009 Bolt, Lug (5/16-24 x 1-3/8") 1 1 9
1022874 Bumper 1 1 10
1030979 Screw, Phillips Pan Head Tap (#10-32 x 3/4") 1 1 11
7930365 Locknut (#10-32) 25 1 12
47565X057 Bushing (7/32 x 3/8 x 11/32") 1 1 13
1023428 Handle, Release, Chrome - Right 1 1 14
1023431 Handle, Release, Chrome - Left 1 1 14
1031330-NLA NLA - Footrest Support w/ Release Handle (Tip,
Bolt and Locknut) Right 1 1 15
1031331-NLA NLA - Footrest Support w/ Release Handle (Tip,
Bolt and Locknut) Left 1 1 15
See Chart Pivot Slide Tube with Aluminum Footplate 1 1 B
A - Before 10/1/00
B - Not Shown
The following pivot slide tubes with footplates are used with the above assembly. For more information on the pivot slide tube or
footplates see page titled "Pivot Slide Tube with Footplate"
Due to design change, for all chairs built prior to 10/1/00 it is suggested that Release Handles be replaced in pairs.
NOTE:
Pivot Slide Tube with Aluminum Footplate
Chair Width Standard 9-1/2" 2" Longer 11-1/2" 4" Longer 13-1/2"
N/A N/A
1020232
14"
See Note(s) A
N/A N/A
1020233
14"
See Note(s) B
1086487 1086486 1017243
16"
See Note(s) A See Note(s) A See Note(s) A
1086489 1086488 1017244
16"
See Note(s) B See Note(s) B See Note(s) B
A - Right
B - Left NOTE:
44
