Invacare 3000 - Manual (Page 42)

Footrest Support Assembly
93M
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1023428 Handle, Release, Chrome - Right 1 1 1
1023431 Handle, Release, Chrome - Left 1 1 1
47565X057 Bushing (7/32 x 3/8 x 11/32") 1 1 2
7930360 Package, Screw, Phillips Pan Head (#10-32 x
11/16") 25 1 3
1008935 Spring, Release - Right 1 1 4
1008936 Spring, Release - Left 1 1 4
7930359 Package, Screw, Phillips Pan Head (#10-32 x 1/2") 25 1 5
1027095 Plug Button, Black (7/8") 1 2 6
11232X009 Bolt, Lug (5/16-24 x 1-3/8") 1 1 7
1107321 Nut, Low Cap (5/16"-24) 1 1 8
04706X035 Tube, Footrest Support, Adult, Chrome - Right 1 1 9
04706X036 Tube, Footrest Support, Adult, Chrome - Left 1 1 9
1030979 Screw, Phillips Pan Head Tap (#10-32 x 3/4") 1 1 10
1022874 Bumper 1 1 11
67005X000 Rivnut (#10-32) 1 1 12
7930365 Locknut (#10-32) 25 1 13
1006490 Tip, Plastic, Black 1 1 14 A
1031191 Footrest Support Assembly, Adult, Chrome - Right 1 1 15
1031192 Footrest Support Assembly, Adult, Chrome - Left 1 1 15
See Chart Pivot Slide Tube with Aluminum Footplate 1 1 B
A - Before 10/1/00
B - Not Shown
The following pivot slide tubes with footplates are used with the above assembly. For more information on the pivot slide tube or
footplates see page titled "Pivot Slide Tube with Footplate".
Due to design change, for all chairs built prior to 10/1/00 it is suggested that Release Handles be replaced in pairs.
NOTE:
Pivot Slide Tube with Aluminum Footplate
Chair Width Standard 9-1/2" 2" Longer 11-1/2" 4" Longer 13-1/2"
N/A N/A
1007274
12"
See Note(s) A
N/A N/A
1007275
See Note(s) B
N/A N/A
1033506
14"
See Note(s) A
N/A N/A
1033507
See Note(s) B
1086487 1086486 1017243
16"
See Note(s) A See Note(s) A See Note(s) A
1086489 1086488 1017244
See Note(s) B See Note(s) B See Note(s) B
41
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 88-139
