Chapter 2. System board features
The PC 300GL supports the following video subsystem modes:
Figure 3. Supported VGA video modes
Mode (hex) Display Mode Screen Resolution Colors Refresh Rate
(Hz)
00 Text 40 x 25 characters B/W 70
01 Text 40 x 25 characters 16 70
02 Text 80 x 25 characters B/W 70
03 Text 80 x 25 characters 16 70
04 Graphics 320 x 200 pixels 4 70
05 Graphics 320 x 200 pixels 4 70
06 Text 640 x 200 pixels 2 70
07 Text 80 x 25 characters Mono 70
0D Graphics 320 x 200 pixels 16 70
0E Graphics 640 x 200 pixels 16 70
0F Graphics 640 x 350 pixels Mono 70
10 Graphics 640 x 350 pixels 16 70
11 Graphics 640 x 480 pixels 2 60
12 Graphics 640 x 480 pixels 16 60
13 Graphics 320 x 200 pixels 256 70
Figure 4 (Page 1 of 3). Supported Enhanced VGA video modes
Mode (hex) Display Mode Screen Resolution Colors Refresh Rate
(Hz)
100 Graphics 640x400 8 70
101 Graphics 640x480 8 60
101 Graphics 640x480 8 70
101 Graphics 640x480 8 72
101 Graphics 640x480 8 75
101 Graphics 640x480 8 85
102 Graphics 800x600 4 60
102 Graphics 800x600 4 72
102 Graphics 800x600 4 75
102 Graphics 800x600 4 85
103 Graphics 800x600 8 60
103 Graphics 800x600 8 70
103 Graphics 800x600 8 75
103 Graphics 800x600 8 85
105 Graphics 1024x768 8 60
105 Graphics 1024x768 8 70
105 Graphics 1024x768 8 75
105 Graphics 1024x768 8 85
107 Graphics 1280x1024 8 60
107 Graphics 1280x1024 8 70
107 Graphics 1280x1024 8 72
Chapter 2. System board features 7
