INTRODUCTION
MB884 User’s Manual 3
MB884 Specifications
Form Factor Micro ATX
CPU Type Intel Pentium 4
CPU Voltage 0.8375V~1.6V (VRD 10.1)
CPU FSB 800MHz
CPU FSB Up to 3.8+ GHz
Green / APM APM1.2
CPU Socket Socket 775
Chipset Intel® 915GV/915G Chipset
GMCH: 915GV/915G 1210-ball FCBGA
ICH6: 82801FB 609-ball mBGA; FWH
BIOS Award BIOS, supports ACPI Function
Cache 1M Level 2 (CPU integrated)
VGA 915GV built-in, supports CRT
Gigabit LAN Marvell 88E8053 PCI-Express Gigabit LAN controller x2
Audio ICH6 Built-in Audio controller + AC97 Codec ALC658 6
Channels (Line-out, Line-in & Mic.)
Memory 2x DDR333/400 SDRAM DIMMs (w/o ECC), Max. 2GB (Dual
Channel)
Parallel IDE ICH6 built-in one channel Ultra DMA 33/66/100
Serial ATA Ports ICH6 built-in Serial ATA Controller, supports 4 ports
USB ICH6 built-in USB Version 2.0, supports 8 ports, implement 6
ports
LPC I/O Winbond W83627HF: IrDA x1, Parallel x1, COM1 (RS232),
COM2 (RS232/422/485), FDC 2.88MB (3-Mode supported),
Hardware monitor (3 thermal inputs, 4 voltage monitor inputs,
VID0-4 & 3 fan headers)
RTC ICH6 built-in w/ on board Lithium Battery
Edge Connector - PS/2 Keyboard & Mouse, Quad USB stack connector x1
for USB1~4, RJ45 connector (w/ Gigabit transformer) x2
for LAN, DB15 x1 for VGA (CRT), DB9 x1 for COM1, DB26
x1 for Printer, Audio Din stack connector x1 for Line-out,
Line-in & Mic
Onboard Header /
Connector - 5x2 pins box-header x1 for COM2
- 4x2 pins pin-header x1 for USB 5~6
- 20x2 pins (2.5mm pitch) box-header x1 for IDE1
- 17x2 pin box-header x 1 for Floppy
- 5 pins pin-header x1 for IrDA
- 10x2 pins pin-header x1 for other features (PWR LED,
Reset, Lock, HDD LED, SPKR, etc.)
Expansion Slots - PCI x2, PCI Express (x1) x1, PCI Express (x16) x1
Power Connector ATX 12V (24 pins + 4 pins)
Watchdog Timer Yes (256 segments, 0, 1, 2…255 sec/min)
System Voltage +5V, +3.3V, +12V, -12V, 5VSB (2A)
Other Function Modem Wakeup & LAN Wakeup
Board Size 244mm x 244mm
