BIOS SETUP
MB884 User’s Manual 43
Integrated Peripherals
Phoenix - AwardBIOS CMOS Setup Utility
Integrated Peripherals
OnChip IDE Device Press Enter ITEM HELP
Onboard Device Press Enter Menu Level
SuperIO Device Press Enter
Onboard Lan Boot ROM
Disabled
OnChip IDE Device
IDE HDD Block Mode
IDE DMA transfer access Enabled
Enabled ITEM HELP
On-Chip Primary PCI IDE Enabled Menu Level
IDE Primary Master PIO Auto
IDE Primary Slave PIO Auto
IDE Primary Master UDMA Auto
IDE Primary Slave UDMA Auto
On-Chip Secondary PCI IDE Enabled
IDE Secondary Master PIO Auto
IDE Secondary Slave PIO Auto
IDE Secondary Master UDMA
IDE Secondary Slave UDMA
Auto
Auto
*** On-Chip Serial ATA Setting ***
On-Chip Serial ATA
Auto
PATA IDE Mode Primary
SATA Port P1,P3 is Secondary
Onboard Device
USB Controller Enabled ITEM HELP
USB 2.0 Controller Enabled Menu Level
USB Keyboard Support Disabled
USB Mouse Support Disabled
Azalia/AC97 Audio Select Auto
Onboard PCI-E Giga LAN1
Onboard PCI-E Giga LAN2
Enabled
Enabled
SuperIO Device
POWER ON Function
KB Power ON Password BUTTON ONLY
Enter ITEM HELP
Hot Key Power ON
Onboard FDC Controller Ctrl-F1
Enabled Menu Level >
Onboard Serial Port 1 3F8/IRQ4
Onboard Serial Port 2 2F8/IRQ3
UART Mode Select Normal
RxD, TxD Active Hi, Lo
IR Transmission Delay Enabled
UR2 Duplex Mode Half
Use IR Pins IR-Rx2Tx2
Onboard Parallel Port 378/IRQ7
Parallel Port Mode SPP
EPP Mode Select
ECP Mode Use DMA EPP1.7
3
PWRON After PWR-Fail Off
