37
Introduction
This chapter gives a general overview of the Machine Type
2169, describes the standard and optional features, and details
functional and environmental specifications.
2169 is a Micro Tower type product
Product Overview
The machine type mentioned above contains two PCI slots and
the system board supports the Intel Celeron processor.
Listed below are system features:
Processors:
•
Socket 370
•
Detachable CPU heat sink with fan.
•
One of the following processors:
−
Intel Celeron 533 MHZ CPU
−
Intel Celeron 566 MHZ CPU
Memory
•
168-pin synchronous dynamic random access memory
(SDRAM), dual inline memory module (DIMM) sockets.
−
2 memory sockets.
−
32-MB, 64-MB, 128MB or 256-MB DIMM.
−
Maximum memory is 256MB.
External Ports
•
Video port (15-pin D-sub connector)
•
Parallel port (25-pin D-sub connector)
•
Serial port (9-pin D-sub connector)
•
Game/MIDI port (15-pin D-sub connector)
•
Keyboard port (6-pin PS/2 mini-din connector)
