PARTS LIST

KEY NO.

DESCRIPTION

Q’ty

1 Main

Frame 1

2

M10 Aircraft Nut

9

3

¾” Washer

14

4

2” x 2 ¾” End Cap

4

5 Rear

Stabilizer

1

6

M10 x 3 ½” Carriage Bolt

4

7

2” Square End Cap

2

8 Brass

Bushing

6

9 Support

Frame

1

10 Lock

Knob

3

11 Sleeve

3

12

Backrest Adjustment Frame

1

13

M10 x 3 3/8” Allen Bolt

1

14 Akimbo

Frame 1

15 Handle

Grip

2

16

Handle Adjustment Frame

1

17

½” Washer

8

18

M8 x 1 1/8” Allen Bolt

4

19

1 ¾” Square End Cap

3

20 Upholstery

Pad 2

21

1” Foam Roll End Cap

4

22 Foam

Roll

4

23 Foam

Tube

2

24

Foot Adjustment Frame

1

25

M10 x 1 3/4” Allen Bolt

2

26 Foot

Plate

1

27

2” Square End Cap

1

28

M8 x 1 5/8” Allen Bolt

2

29 Roller

Wheel 2

30

M8 Aircraft Nut

2

31

M10 Round Allen Bolt

4

32 Front

Stabilizer 1

33

M10 x 3 ½” Allen Bolt

2

34

M10 x 1” Allen Bolt

1
