Intel OPEN (660) 120/140/150 II User Manual
Page 74
User Manual version 2.1
OPEN (660) 120/140/150
6-64
6.2.1. Jumpers & Jumper Setting
The table below lists the function of each jumper. The
related jumper settings are shown in the coming
sections.
Jumper
Description
JP1
LCD power setting
JP2
Reserved
JP4
CMOS clear
JP3
COM2 RS-232/485 selection
JP5
COM2 RS-232/485 selection
JP6
COM2 RS-232/485 selection
JP7
CPU frequency setting
JP9
DiskOnChip 2000 address setting
