User Manual version 2.1
OPEN (660) 120/140/150
9-133
A-1-1-3. A
BSOLUTE
M
AXIMUM
R
ATINGS
I
TEMS
S
YMBOL
M
IN
. M
AX
. U
NIT
Power Supply Voltage for LCD V
CC
0 5.5 V
Input Voltage V
IN
-0.5 V
CC
+0.5 V
Operating Temperature T
op
0 50 o C
Storage Temperature T
stg
-20 60 o C
Note: Humidity <= 85%, non-condensing
A-1-1-4. E
LECTRICAL SPECIFICATION
LCD
MODULE
I
TEMS
S
YMBOL
M
IN
T
YP
. M
AX
. U
NIT
Power Supply Voltage V
CC
3.0 3.3 3.6 V
“H” level LVDS signal input V
LH
2.5 - V
CC
V
“L” level LVDS signal input V
LL
0 - 0.6 V
Power supply current I
CC
- 260 350 mA
Ripple voltage V
RP
- - 100 MV
BACKLIGHT
(1
LAMP
) Ta=25+-2 o C
I
TEMS
S
YMBOL
M
IN
. T
YP
. M
AX
. U
NIT
Lamp voltage V
L
- 620 - V
Lamp current I
L
- 4.5 *3 5.0 mA
Startup Voltage V
S
1100 V
Connector Information of Backlight unit
P
IN
S
YMBOL
D
ESCRIPTION
1 CTH VBLH (High voltage)
2 CTL VBLL (Low voltage)
Note: VHLH-VBLL=VL
** Backlight side connector. BHR-03VS-1 (JST)
** Invertor side connector: SM02(8.0)B-BHS (JST)
