14 TROUBLESHOOTING

Part No. 1143205

Lynx™L-3 & Lynx L-4 Scooters

14.3 Resetting the Circuit Breaker

To reset, press the circuit breaker button located below the seat.

FIGURE 1 Resetting the Circuit Breaker

WARNING

NEVER defeat or bypass the circuit breaker. ONLY replace with a circuit breaker of the same rating.



For this procedure, refer to FIGURE 1.
Key must be removed from ignition before resetting circuit breaker.
Lynx L-3 shown. Lynx L-4 circuit breaker button is in the same location.
Resetting the circuit breaker may be needed if the scooter does not turn on and the reset button has popped out about .25

inch.

Circuit Breaker Button

Seat
