11 TRANSPORTING
44
11 Transporting
11.1 Transporting the Scooter
Disassembling
1.
Turn power off and remove the key from the ignition.
2.
Remove the basket.
3.
Remove the seat. Refer to Removing/Installing the Seat on page 23.
4.
Remove the battery box. Refer to Removing/Installing the Battery Box on page 30.
5.
Hold the seat post with one hand (Detail “A”).
6.
With the other hand, push the release lever to the rear of the scooter.
7.
Lift the seat post to separate the front frame assembly from the rear frame assembly (Detail “B”).
8.
Fold tiller down to lowest locked position. Refer to Adjusting the Tiller Angle on page 26.
ƽ
WARNING
After any adjustments, repair or service and before use, make sure that all attaching hardware is tightened securely -
otherwise injury or damage may result.
Before performing any maintenance, adjustment or service, turn power off and remove key from ignition.
DO NOT lift the scooter by the rear shroud - otherwise damage to the scooter may occur.
