PARTS LIST
KEY NO. DESCRIPTION QUANTITY
1 Right Upright Beam 1
2 Left Upright Beam 1
3 Main Seat Support 1
4 Cross Brace 1
5 Front Leg 1
6 Arm Curl Stand 1
7 Leg Developer 1
8 Weight Post 2
9 Main Seat Stabilizer 1
10 Backrest Support 2
11 Foam Tube 2
12 Curved Bracket 2
13 Lock Knob 1
14 2 3/8” Rubber Bumper 2
15 1” Square End Cap 2
16 Ø 1” End Cap 8
17 Upright End Cap 2
18 Ø ¾” Bushing 2
19 Backrest Adjustment Bar 1
20 Front Leg End Cap 1
21 Ø 2 3/8” x Ø 2” Sleeve 1
22 Ø 2” End Cap 3
23 Ø 1” Con-shaped End Cap 2
24 Foam Roll 4
25 Arm Curl Pad 1
26 Seat Pad 1
27 Backrest Board 1
28 M8 Aircraft Nut 1
29 M10 x 3 1/8” Carriage Bolt 4
30 M10 x 2 ½” Carriage Bolt 2
31 M8 x 5/8” Allen Bolt 6
32 M8 x 3 1/8” Allen Bolt 1
33 M10 x 1” Allen Bolt 2
34 M6 x 1 ½” Hex Bolt 4
35 Ø ¾” Washer 6
36 Ø 5/8” Washer 8
37 Ø ½” Washer 8
38 Curved Washer 2
39 ST5 Screw 2
40 M10 Aircraft Nut 6
41 M6 x 1 ¼” Hex Bolt 4
