Page 17: Caution
4 OPERATION
17
Invacare®MA80 Series Mattresses
5.
Ensure the hose connector is flush with the control unit connector.
FIGURE 3 Connecting the Hose
4.5
Connecting the Power Cord
ƽ
WARNING
DO NOT alter plug to fit a non-conforming outlet. Instead, have an electrician install a properly grounded outlet. Failure to
use the correct plug and outlet can result in a potential safety hazard.
CAUTION
Ensure that the power cord of the control unit is not pinched, or has any objects placed on it, and also ensure it is not
located where it can be stepped on or tripped over.
Connector Cover
Control Unit
Connector
Holes
Hose
Connector
DETAIL “A”
Control Unit
