Part No. 1106665 1 Solara jr.™ Ventilator Tray
SAVE THESE INSTRUCTIONS
NOTE: Check all parts for shipping damage. In case of damage, DO NOT use. Contact Carrier/Invacare
for further instructions.
SAFETY SUMMARY
To ensure the safe and proper installation and use of the Ventilator Tray, these instructions
MUST be followed:
GENERAL WARNING
DO NOT install this equipment without first reading and understanding this
instruction sheet and the Solara jr. Owner’s Manual, part number 1106628. If
you are unable to understand the warnings, cautions and instructions, contact a
healthcare professional, dealer or technical personnel if applicable, before
attempting to install this equipment - otherwise, injury or damage may occur.
INSTALLATION WARNING
After ANY adjustments, repair or service and BEFORE use, make sure that all
attaching hardware is tightened securely.
NOTE: The ventilator tray kit can only be installed on 16-inch wide Solara jr. wheelchairs. If necessary,
adjust the width of the wheelchair. Refer to the Solara jr. Service Manual, part number 1106629.
This kit includes the following items:
Description Quantity
Plug Button 2
Washer 2
Locknut 2
Side Mounting Screw 2
Ventilator Tray with six (6) Straps 1
Rear Ventilator Tray Crossmember 1
Solara jr.™ Ventilator Tray
Assembly, Installation and Operating Instructions
Kit No. 1108526
